Barload

Long Bar Feeders

VITO 56

Features

  • Adjustment-free for different bar sizes.
  • Hidden-and-secured wiring.
  • Speedy bar change-over.
  • Adjustable torque force and speed.
  • Improved design for separating lubricant and remnant collection.

Specifications

Specifications

Guide channel 21mm/27mm/33mm/37mm/39mm/
43mm/46mm/52mm/57mm
Bar diameter 5-20mm/5-26mm/5-32mm/5-36mm/
5-38mm/5-42mm/5-45mm/
8-51mm/8-56mm
Bar capacity 10mm/26pcs
Bar length 2700mm/3200mm/3800mm
Machine weight 2.5M-860kg/3.0M-950kg /3.6M -1060kg
Air pressure 6kgf /cm2(70psi)
Transmission Servo motor
Lubricant FK ISO VG68/ FK hydraulic oil 68
Capacity 38L
Power consumption 810W
Power supply 3 X 220V 50/60Hz



Short Bar Feeders

BA65

  • Increases productivity and cuts production costs.
  • Suits for profiled bar materials such as hex. & square.
  • Compact design requires less floor space.
  • User Friendly with a Human-Machine-Interface application.
  • Feed materials accurately with a linear-guide system.
  • An easy changeover with a V-channel-loading system.
  • External LED display features bar position & length while fed.
  • Offers a vibration free operation with unlimited rpm.

Specifications

Specifications

Bar length  1200mm-1500mm
Machine weight 320KGS-360KGS
Bar Diameter 5-65mm
Bar capacity 65mm/10pcs
Air pressure 6kgf/cm2(70psi)
Power supply  1x220V
Power consumption  200W

BS65

  • Productivity increases and reduces manufacturing costs.
  • No rpm limit leads to vibration free operation.
  • Fast and smooth bar loading cycle.
  • Smooth pushing motion combines with right liner guide sets.
  • V-guide channel set adjusts easily for bar loading.
  • Convenient remote controller.
  • External LED displays bar material position and alarms.
  • 'X' Linear Rails moves bar feeder to allow access to spindle liner and maintenance.
  • Servo feeding features accurate positioning bar without a turret stop.
  • HMI screen display shows alarm messages, easy for trouble shooting.

Specifications

Specifications

Bar diameter  5-65mm
Bar capacity 65mm/10 pcs
Max Bar length 1200mm/1500mm/1800mm
Depends on machine spindle length
Machine weight 265KGS - 280KGS - 330 KGS
Air pressure 6kg/cm2(70psi)
Power supply 1x220V
Power consumption 575W

BSM80

  • Accurate processing of workpieces.
  • Fast and accurate servo feeding system.
  • Bar changeover controls via a Human-Machine-Interface display.
  • External LED displays bar position and alarms.
  • Cycling time for bar changeover runs less than 15sec

Specifications

Specifications

Bar length  1200mm- 1500mm
Material diameter 8-80mm
Bar capacity 80mm/7pcs
Machine weight  285kgs
Motor  Servo motor
Power supply 1x220v 60hz/1x380v 50hz
Power consumptions 640W

BK105

  • Increase productivity and reduce manufacturing cost.
  • No vibrations, allow precision machining at high speed.
  • Stronger mechanical design, max bar diameter up to 105mm.
  • Servo feeding system, provides accurate bar positioning without turret stopper.
  • Adjustment free bar diameter changes.
  • External LED display, easily monitor feeding and alarm situation.

Specifications

Specifications

Bar length  1100mm-1600mm
Machine weight 600KG-700KG
Bar diameter  8mm-105mm
Bar capacity 105mm/5pcs
Power supply 1x220V
