CC Machinery

Slant Bed Turning Centers

CT1

CT1

A new standard in precision machining

  • 45 degree slant bed structure for excellent stability
  • Roller type linear guideways with excellent repeatability
  • Chiah Chyun self-designed and manufactured live turrets

Specifications

Specifications

Max. manu. dia. Ø330mm
Standard manu. dia. Ø210mm
Swing over bed diameter  Ø846mm
Distance between two center 1061mm
Max. manu. length 740mm
Bar capacity F: Ø65    M: Ø76
X axis travel  230mm
Z axis travel  603mm
Y axis travel ±50mm
B axis travel 744.5mm
X, Y, Z axis rapid travel speed  16/6/40m/min
B axis rapid travel speed 40m/min
Spindle max rpm 4000rpm
Spindle bore F: Ø86    M: Ø88
Spindle bar capacity F: Ø65    M: Ø76
Chuck Size 8"
Sub Spindle max. 4000rpm
Sub Spindle bore  Ø86
Spindle bar capacity Ø65
Chuck Size 8"
C axis rapid travel speed  600min-1

CT2-52YM

CT2-52YM

  • Double turret with 16-station live tooling
  • Single Y axis
  • Double built-in spindle
  • Built-in Type Spindle - The built-in spindle performing short accelerate/decelerate time and low vibration characteristic, it provide high precision and high efficient capability.
  • Motor: 7.5/11kw
    • 6000rpm (standard) / 4000rpm (optional)
    • A2-5 spindle nose
    • Spindle cooling
  • Oil Mist Lube System

The oil mist lube system provides lubrication oil for the gears in the turret, that supply for reducing the mist continuously and lower the temperature of gear.

Specifications

Specifications

Max. manu. dia.  ∅330mm
Standard manu. dia ∅210mm
Swing over bed diameter  ∅830mm
Distance between two center 920mm
Max. manu. length  400mm
Bar capacity  ∅51
X1, X2, X3 axis travel   227.5/230mm
Z1, Z2, Z3 axis travel   440/440mm
Y1, Y2 axis travel ± 50mm
X, Y, Z axis rapid travel speed  650mm
B axis rapid travel speed 16/6/40m/min
Min. input unit  40m/min
Spindle max.  0.001
Spindle bore  6000rpm
Spindle bar capacity  ∅60.5
Chuck size  6"/8"
Spindle max. 6000rpm
Spindle bore ∅60.5
Spindle bar capacity ∅51
Chuck size  6"/8"
C axis rapid travel speed   600min-1
Live tool rpm  60~6000min-1
No. of  live tools  16 × 2
Collet size ER∅32


WTS-52Y2M

Features

  • Twin Spindle & Twin Turret & Double Y Axis
  • E-Axis for 2 Separate Work Areas
  • Double Y Axis 16-Station Upper and Lower Turrets

Specifications

Specifications

Max. manu. dia.      ∅370mm
Standard manu. dia.      ∅210mm
Swing over bed dia.      ∅780mm
Distance between two center of spindle nose      814mm
Max. manu. length      500mm
Bar capacity      ∅51mm
X1/X2-axis travel      215/230mm
Z1/Z2-axis travel      550/550mm
Y1,Y2-axis travel      ± 50mm
B-axis travel      550mm
E-axis travel      170mm
Max. spindle speed      6000rpm
Spindle nose      A2-5
Power      220V, 80KVA, 3phase
Machine size(LxWxH) (includes chip conveyor)      4162*2265*2226



CT3-52Y2M

Features

  • Twin spindle & Three Turret
    CT3 can perform complex machining faster and more economically in one setup.
  • Whether you produce complex or simple parts at high production rates, CT3 with twin spindle and three turrets offers unbeatable versatility. This machine consists of three 16-position servo turrets that will dramatically upgrade machining efficiency and maximize productivity.

Specifications

Specifications

Max. manu. dia.     Ø330 mm
Standard manu. dia.    Ø210 mm
Swing over bed dia.     Ø830 mm
Distance between two center     1045
Max. manu. length     320
Bar capacity    Ø51
X1, X2, X3 axis travel     227.5/230/227.5
Z1, Z2, Z3 axis travel     310/440/250
Y1, Y2axis travel     ± 50/± 50
B axis travel     762
X, Y, Z axis rapid travel speed    16 / 6 / 40 m/min
Max. spindle speed     4000rpm
Machine size(LxWxH) (includes chip conveyor)     4327x2335x2164
Power     67KVA
Machine N.W.
(includes chip conveyor)
11120kgs



CT3-76Y2M

Feature

  • Twin spindle & Three Turret
  • CT3 can perform complex machining faster and more economically in one setup.
  • Whether you produce complex or simple parts at high production rates, CT3 with twin spindle and three turrets offers unbeatable versatility. This machine consists of three 16-position servo turrets that will dramatically upgrade machining efficiency and maximize productivity.

Specifications

Specifications

Max. manu. dia.     Ø330 mm
Standard manu. dia.     Ø210 mm
Swing over bed dia.     Ø830 mm
Distance between two center     1045
Max. manu. length 300
Bar capacity Ø76
X1, X2, X3 axis travel     227.5/230/227.5
Z1, Z2, Z3 axis travel 285/425/250
Y1, Y2axis travel     ± 50/± 50
B axis travel 680
X, Y, Z axis rapid travel speed     16 / 6 / 40 m/min
B axis rapid travel speed     40m/min
Max. spindle speed 4000rpm
Spindle nose     A2-6
Machine size(LxWxH) (includes chip conveyor)     4327x2335x2164



Swiss Type Turning Center

CB32M/CB36M

CB32M/CB36M

Complete complicated parts machining in one operation:

The twin spindle features a complete driven tooling system and the Y axis main spindle delivers high efficiency and outstanding production capability. The back machining capability can save time and reduce labor costs, creating a huge productive benefit when machining complex workpieces.

Specifications

Specifications

Max. manu. dia. Ø32     Ø36
Bar capacity  Ø32     Ø36
X axis travel 185mm
Y axis travel 490mm
Z axis travel 165mm
X,Y,Z axis rapid travel speed 30m/min
Spindle max.  6000rpm
Spindle motor 5.0kw, 7.0kw opt.
Spindle bar capacity Ø36
Max. manu. dia. Ø32
Sub spindle max. 6000rpm
Sub spindle motor 3.5kw
Sub spindle bore Ø28
Sub spindle bar capacity Ø32
No. of turning tool  4
Radial live tooling max. speed   6000rpm
Axial live tooling max. speed 6000rpm
NCY-32M

NCY-32M

Cut Machining Cost.

Increase Productivity & Profit.

NCY-32M Sliding Head CNC Lathe performs turning, milling, drilling, tapping, cutting and slide turning, all in one operation. Our sliding headstock design, combined with PC-based CNC control, offers high efficiency and precise machining.



Specifications

Specifications

Max. manu. dia. Ø32
Y axis travel 490mm
X axis travel  190mm
Z axis travel 165mm
X,Y,Z axis rapid travel speed 30m/min
Spindle max.   6000rpm
Spindle motor 7.0kw
Spindle bar capacity  Ø32
Spindle live tooling
No. of cross side driving tools 4
No. of front side driving tools 3
Axial live tooling servo motor 0.75kw
Radial live tooling servo motor 1.5kw
Rev. speed of driving tools 6000rpm Stepless speed


CDS 42 (Twin Spindle Twin Platten - Gang Type)

Feature



  • Built for High Accuracy and High Production Operation
  • The CDS machine features a slant bed with an independent gang tool table for main and sub spindle. This saves tool changing time and shortens the cycle time.

Specifications

Specifications

Max. manu. dia.      Ø42
Spindle max. rpm      6000 rpm
X1-axis travel(vertical)      330
Z2-axis travel(cross)     240
Max. bar feeding dia.      Ø42
Collet of spindle      TRB-42
X rapid travel speed      30 m/min
Z rapid travel speed      30 m/min
Sub Spindle Max. manu. dia.     Ø42
Sub spindle max. rpm     6000 rpm
Sub spindle servo motor     5.5/7.5kw
Coolant pump      3/4 HP
Machine size(LxWxH)      2620 x 1270 x1700
Machine N.W.      3300 kgs
Coolant tank capacity      210 L



CDS 32 (Twin Spindle , Twin Platten - Gang Type )

Feature



  • Built for High Accuracy and High Production Operation
  • The CDS machine features a slant bed with an independent gang tool table for main and sub spindle. This saves tool changing time and shortens the cycle time.

Specifications

Specifications

Max. manu. dia.      Ø32
Spindle max. rpm      6000 rpm
X1-axis travel(vertical)      330
Z2-axis travel(cross)     240
Max. bar feeding dia.      Ø32
Collet of spindle      TRB-32
X rapid travel speed      30 m/min
Z rapid travel speed      30 m/min
Sub Spindle Max. manu. dia.     Ø32
Sub spindle max. rpm     6000 rpm
Sub spindle servo motor     5.5/7.5kw
Coolant pump      3/4 HP
Machine size(LxWxH)      2620 x 1270 x1700
Machine N.W.      3300 kgs
Coolant tank capacity      210 L



CDS 52

Feature:

Built for High Accuracy and High Production Operation
The CDS machine features a slant bed with an independent gang tool table for main and sub spindle. This saves tool changing time and shortens the cycle time.


Specifications

Specifications

X1,X2-axis travel(vertical)     330mm
Z1,Z2-axis travel(cross)      240mm
X-axis servo motor      1.0 kw
Z-axis servo motor      1.0 kw
X rapid travel speed      30 m/min
Z rapid travel speed      30 m/min
Min. input unit      0.001
Spindle
Max. bar feeding dia.       Ø51
Max. manu. dia.         Ø51
Center height      1070
Spindle max. rpm      6000 rpm
Spindle servo motor     7.5/11kw
Collet of spindle       TRB-52
Sub Spindle
Max. bar feeding dia.        Ø51
Max. manu. dia.        Ø51
Center height      1070mm
Sub spindle max. rpm      6000 rpm
Sub spindle servo motor     7.5/11kw
Coolant pump
Main/Sub spindle upper flush pump     3/4HP.
Tool coolant pump     3/4HP.
Machine
Power     220V/42KVA
Machine size(includes chip conveyor)(LxWxH)     3645x1273x1945
Machine N.W.     4500kg




Multi Tasking Turning Center

CT3-65Y2M

CT3-65Y2M

  • Double Built-in Spindle with 65 model
  • Double Y axis for versatile milling
  • Three Servo Turret
  • Total 48 Station Live Tooling

Specifications

Specifications

Max. Manu. Dia. Ø210
Standard Manu. Dia. Ø190
Max. Swing Dia. Ø210
Distance Between Two Center 1045mm
Max. Manu. Length 320mm
Bar Capacity Ø51
X1, X2, X3 Axis Travel 227.5/230/227.5mm
Z1, Z2, Z3 Axis Travel 310/440/250mm
Y1, Y2 Axis Travel ±50mm
B Axis Travel 762mm
X, Y, Z Axis Rapid Travel Speed 16/6/40m/min
B Axis Rapid Travel Speed 40m/min
Max. Spindle speed 6000rpm
Spindle Motor  7.5/11kw
Spindle Bore Ø60.5
Spindle Bar Capacity     Ø51
Max. Sub Spindle speed 6000rpm
Spindle Motor 7.5/11kw

CY2-52MB (With B-axis for angle hole drilling )

Features

  • The CY2-52MB CNC turning milling center combines double built-in spindle, double Y axis and B axis live tooling functions. This milling center can greatly reduce machining time and raise overall production efficiency.
  • The B axis live tooling system provides high precision for indexing accuracy up to 0.001° and can rotate 360°, supplying angular machining capability.

Specifications

Specifications

Max. manu. dia.      Ø51mm
Bar capacity      Ø51mm
Spindle max. rpm       6000 rpm
X1 axis travel     200mm
Y1 axis travel      455mm
Z1 axis travel      192mm
Max. bar feeding dia.       Ø51mm
Collet of spindle      TRB-52
X1, Y1, Z1 rapid travel speed      30 m/min
No. of Axial and Radial driven tool     12
Sub spindle Max. manu. dia.       Ø51
Machine N.W. (includes chip conveyor)      6000 kg
Machine size (LxWxH) (includes chip conveyor)     3400x1921x2080
