CNC Flat Bed Turning Center

CKE6150Z x 1500 mm

  • All main components, bed, headstock, saddle, plinth etc are high quality solid castings
  • Low friction Turcite-B coating on all surfaces between saddle and guideways
  • Precision ballscrews and highly rigid precision bearings ensure accurate positioning and heavy cutting capability
  • Centralised oil system provides forced automatic lubrication onto ballscrews and surfaces
  • Choice of two model ranges. THE CKE-Z series has automatic headstock gear change, wide range high spindle speed and low noise levels of under 80db. The CKE-i series, with independent spindle structure, utilises a frequency converted spindle motor or servomotor to offer stepless high spindle speeds.
  • Operator adjustable control panel enables convenient tool setting
  • Fully enclosed guards with interlock offer a waterproof and chip-free environment
  • Horizontal 4-P automatic indexing toolpost is provided as standard, while vertical 4-P toolpost, horizontal 6-P toolpost, quick-change toolpost etc can also be supplied to suit customers’ specific requirements
  • Optional pneumatic or hydraulic chuck and tailstock are available

Brochure

Specifications

Specifications

Max. swing over slide 280mm
Bed width 400mm
Spindle taper D8
Spindle speeds 7-2200 1/min
Spindle bore 82mm
Transmission ratio 3 steps (auto)
Tailstock quill diameter 75mm
Taper of tailstock quill 5 MK
Tailstock quill stroke 150mm
Max. length of work piece 1500mm
X-travel 280mm
Z travel  1430mm

CKE6136

Features

  • All main components, bed, headstock, saddle, plinth, etc., are high quality solid castings
  • Low friction Turcite-B coating on mating surfaces between saddle and guideways.
  • Precision ballscrews and highly rigid precision bearings ensure accurate positioning and heavy cutting capability.
  • Centralized oil system provides forced automatic lubrication onto ballscrews and all mating surfaces.
  • Operator adjustable control panel enables convenient tool setting.
  • Optional pneumatic or hydraulic chuck and tailstock are available.

Brochure

Specifications

Specifications

Max. Swing over bed                   630 mm
Width of bed                    550 mm
Max. Length of work piece              1000 mm
X travel                          320 mm
Z travel                          2735 mm
Spindle nose                      C11
Chuck size                       320 mm
Taper of spindle bore                  1:20
Spindle bore                       100 mm
Frequency conversion motor power           11 kW
Rapid traverse X/Z                  4/8 m/min
Repeatability of tool post                   0.008 mm
Diameter of tailstock quill                   100mm
Travel of tailstock quill                   240mm
Taper of tailstock quill                 M6
Net weigh                       4500 Kg



CKE 6140Z x 1000mm (Generally Ex Stock)

Feature

  • Available with Siemens 808D, Siemens 828D Basic (Shopturn) , Fanuc Oi , Fagor control systems
  • 394mm Width of Bed
  • 1000mm Workpiece Length
  • All main components, bed, headstock, saddle, plinth, etc., are high quality solid castings.
  • Low friction Turcite-B coating on mating surfaces between saddle and guideways.
  • Precision ballscrews and highly rigid precision bearings ensure accurate positioning and heavy cutting capability.
  • Centralized oil system provides forced automatic lubrication onto ballscrews and all mating surfaces.
  • Operator adjustable control panel enables convenient tool setting.

Brochure

Specifications

Specifications

Max. Swing over bed                      400 mm
Width of bed                         300 mm
Max. Length of work piece                   1000 mm
Max. Swing over slide                      200 mm
X travel                             225 mm
Z travel                               680mm
Spindle nose                         D6
Chuck size                          200 mm
Taper of spindle bore                      M6
Spindle bore                          52 mm
Steps of spindle speed                      2-step actuator
Frequency conversion motor power               5.5 kW
Rapid traverse X/Z                       4/5m/min
Repeatability of tool post                      0.008 mm
Horizontal 6-position Tool post changing time         3
Diameter of tailstock quill                      63mm
Travel of tailstock quill                       130mm



CKE 6150Z x 2000mm

Features

  • All main components, bed, headstock, saddle, plinth, etc., are high quality solid castings.
  • Low friction Turcite-B coating on mating surfaces between saddle and guideways.
  • Precision ballscrews and highly rigid precision bearings ensure accurate positioning and heavy cutting capability.
  • Centralized oil system provides forced automatic lubrication onto ballscrews and all mating surfaces.
  • Operator adjustable control panel enables convenient tool setting.
  • Optional pneumatic or hydraulic chuck and tailstock are available.



Specifications

Specifications

Max. Swing over bed                     400 mm
Width of bed                          300 mm
Max. Length of work piece                   2000 mm
Max. Swing over slide                       200 mm
X travel                              225 mm
Z travel                             680mm
Spindle nose                         D6
Chuck size                          200 mm
Taper of spindle bore                      M6
Spindle bore                          52 mm
Steps of spindle speed                     2-step actuator
Frequency conversion motor power               5.5 kW
Rapid traverse X/Z                      4/5m/min
Repeatability of tool post                       0.008 mm
Horizontal 6-position Tool post changing time
Diameter of tailstock quill                       63mm
Travel of tailstock quill                       130mm
Taper of tailstock quill                      M4
Net weigh                           1800Kg
Overall dimensions                      2300 x1480 x1520mm



CKH 6156 X 1000

Features

  • The machine adopts horizontal straight bed layout. Main machine bodies, i.e. bed, leg, etc are made of resin sand-casting through timing treatment, which ensures superb-stability of the machine.

Specifications

Specifications

Max. swing over bed  560 mm
Max. swing over cross slide  330 mm
Distance between centers  1000 mm
Spindle bore diameter 82 mm
Spindle speed 3-3000rpm
Main Motor power 11/15 kw



CKH 6156 X 2000

Feature

  • The machine adopts horizontal straight bed layout. Main machine bodies, i.e. bed, leg, etc are made of resin sand-casting through timing treatment, which ensures superb-stability of the machine.

Specifications

Specifications

Max.Swing over bed  560 mm
Max. Swing over cross slide 330 mm
Distance between centers 2000mm
Spindle bore diameter 82 mm
Spindle speed  3-3000 rpm
Main motor speed  11/15 Kw



CKH 6180 X 1000

Feature

  • The machine adopts horizontal straight bed layout. Main machine bodies, i.e. bed, leg, etc are made of resin sand-casting through timing treatment, which ensures superb-stability of the machine.

Specifications

Specifications

Max.Swing over bed  800 mm
Max.Swing over cross slide  490 mm
Distance between centers 1000 mm
Spindle bore diameter 105 mm
Spindle speed  2-150 rpm
Main Motor Power  15/18.5 kW



CKH 6180 X 4000

Feature

  • The machine adopts horizontal straight bed layout. Main machine bodies, i.e. bed, leg, etc are made of resin sand-casting through timing treatment, which ensures superb-stability of the machine.



Specifications

Specifications

Max. Swing over bed  800 mm
Max. Swing over cross slide 490 mm
Distance between centers  4000 mm
Spindle bore diameter 105 mm
Spindle speed 2-1500 rpm
Main motor power  15/18.5 kW



Lathes

CDL 6241 (Entry Level Lathe - Generally Ex Stock)

Features

  • 3-jaw chuck
  • Steady rest
  • Follow rest
  • Center tools
  • Face plate
  • Drive plate
  • Toolpost guard
  • Chuck guard
  • Full splash guard
  • Oil gun
  • Foundation bolts
  • Toot brake.

Brochure

Brochure

PDF icon CDL Series.pdf

Specifications

Specifications



Max.Swing over bed 410mm
Max.Swing over carriage 230mm
Max. Swing in gap 640mm
Max.Length of workpiece 750 / 1000 / 1500mm
Spindle speed 32-2000rpm
Spindle bore 52mm
Maximum spindle motor power    3/4.5kw
Tailstock quill diameter    60mm
Tailstock quill taper No 4 MT
Tailstock quill travel 150mm

CDL 6251

Features

  • 3-jaw chuck
  • Steady rest
  • Follow rest
  • Center tools
  • Face plate
  • Drive plate
  • Toolpost guard
  • Chuck guard
  • Full splash guard
  • Oil gun
  • Foundation bolts
  • Toot brake.

Specifications

Specifications

Max.Swing over bed 510mm
Max.Swing over carriage 320mm
Max. Swing in gap 735mm
Max. Length of workpiece 750 / 1000 / 1500mm
Spindle speed 16-1600rpm
Spindle bore 82mm
Maximum spindle motor power 5.5kw
Tailstock quill diameter 60mm
Tailstock quill taper No 4 MT
Tailstock quill travel 150mm

CDS 6266C (Heavy Duty Lathe)

Features

  • 3-jaw chuck
  • Steady rest
  • Follow rest
  • Center tools
  • Face plate
  • Drive plate
  • Toolpost guard
  • Chuck guard
  • Full splash guard
  • Oil gun
  • Foundation bolts
  • Tool brake.



Specifications

Specifications

Swing over bed 660mm
Swing over cross slide 440mm
Swing in gap 870mm
Gap length 250mm
Dist. centers 1000/1500/2000/3000
Spindle bore 105mm
Taper of spindle bore 110/120mm
Spindle nose D8
No.of Spindle speed 16
Spindle speed ranges 26-1700rpm
Max spindle motor power 7.5kW(10HP)
Width over bedways 394mm
Cross slide travel - X axis 355mm
Travel of top slide 150mm
Max.dimension of tool shank 25×25mm
Range of Imperial Pitches 16-80TPI
Range of Diametral Pitches 8-160DP
Range of Metric Pitches 0.35-80mm
Range of Module Pitches 0.2-40MOD
Tailstock quill diameter 75mm
Tailstock quill taper No 5 MT
Tailstock quill travel 150mm
CW62100 X 5000mm heavy duty lathe

CW62100 X 5000mm

Specifications

Specifications

Max. swing over bed 1000mm
Max. swing over carriage 720mm
Center distance    750mm/1000mm/1500mm/2000mm
  3000mm/4000mm/5000mm/6000mm
Width of gap 320mm
Swing over gap 1230mm
Width of guide way 550mm
Spindle bore diameter 130mm
Spindle speed (18 speeds) 7.5~1000rpm
Longitudinal feed (64) 0.1~24.3mm/r
Cross feed (64) 0.05~12.15mm/r
Rapid traverse speed 3.8m/min
Metric thread (39)1~240mm
Inch thread (26) 14~1TPI
Module thread (53) 0.5~120mm
Diametrical pitch thread (24) 28~1
Max. travel of cross slide 493mm
Travel of top slide 200mm
Main motor power 11kw
Rapid traverse motor power 1.1kw
Coolant pump motor power 0.09kW



CDS6250

Features

  • 3-jaw chuck
  • Steady rest
  • Center tools
  • Face plate
  • Drive plate
  • Toolpost guard
  • Chuck guard
  • Full splash guard
  • Oil gun
  • Foundation bolts
  • Tool brake

Specifications

Specifications

Swing over bed                                                      500mm
Swing over cross slide  290mm
Swing over gap  760mm
Gap length  280mm
Dist. centers 750/1000/1500/2000/3000
Spindle bore 82/105
Taper of spindle bore  90/1:20
Spindle nose  D8
No. of Spindle speed  16
Spindle speed ranges 26-2000/26-1700rpm
Maximum spindle motor power  705kw(3/10HP)
Width over bedways  394 mm
Cross slide travel X axis  355mm
Travel of top side  150mm
Max. dimension of tool shank  25 x 25 mm
Range of Imperial Pitches  7/16-80 TPI
Range of Diametral Pitches  7/8-160DP
Range of Metric Pitches  0.35-80 mm
Range of Module Pitches  0.2-40 MOD
Tailstock quill diameter 75 mm
Tailstock quill taper  No. 5MT
Tailstock quill travel  150 mm
