Vertical Machining Centres

GSM 800S

  • This machine is constructed with heavy-duty Meehanite cast iron to ensure high rigidity, wear resistance, and no deformation.
  • The X, Y and Z axis slideways are coated with Turcite-B to assure smoothness and abrasion resistance.
  • The X, Y, and Z axis adopt high precision double nuts pre-loaded type ball screws.
  • P4-grade precision bearing is adopted for the main spindle.

Specifications

Specifications

TABLE
Worktable 355x1270mm
T-slot 16x3x64mm
Table load capacity 500kgs
MOVEMENT
X axis travel 800mm
Y axis travel 400mm
Z axis Travel 450mm
SPINDLE HEAD
Spindle taper BT-40
Spindle speed 6000rpm/ 8000, 10000, 12000rpm opt.
Feed Rate 0-5m/min
Ballscrew diameter Ø32m/min
Rapid travel 0-10m/m
MOTORS
Spindle motor 7.5HP
Tool storage capacity 16


GSM 1000S

  • This machine is constructed with heavy-duty Meehanite cast iron to ensure high rigidity, wear resistance, and no deformation.
  • The X, Y and Z axis slideways are coated with Turcite-B to assure smoothness and abrasion resistance.
  • The X, Y, and Z axis adopt high precision double nuts pre-loaded type ball screws.
  • P4-grade precision bearing is adopted for the main spindle.

Specifications

Specifications

TABLE
Worktable 406x1372mm
T-slot 16x3x64mm
Table load capacity 600kgs
MOVEMENT
X axis travel 1000mm
Y axis travel 500mm
Z axis Travel 520mm (600)
SPINDLE HEAD
Spindle taper BT-40
Spindle speed 6000rpm, 8000, 10000, 12000 opt.
Feed Rate 0-5m/min
Ballscrew diameter Ø32m/min
Rapid travel 0-10m/min (0-20)
MOTORS
Spindle motor 10HP
Tool storage capacity 16


GSM 1500S

  • This machine is constructed with heavy-duty Meehanite cast iron to ensure high rigidity, wear resistance, and no deformation.
  • The X, Y and Z axis slideways are coated with Turcite-B to assure smoothness and abrasion resistance.
  • The X, Y, and Z axis adopt high precision double nuts pre-loaded type ball screws.
  • P4-grade precision bearing is adopted for the main spindle.

Specifications

Specifications

TABLE
Worktable 450x1800mm
T-slot     16x5x60mm
Table load capacity     1000kgs
MOVEMENT
X axis travel              1500mm
Y axis travel             650mm
Z axis Travel               620mm
SPINDLE HEAD
Spindle taper         BT-40
Spindle speed  6000rpm, 8000, 10000, 12000rpm opt.
Feed Rate                 0-5m/min
Ballscrew diameter            Ø40m/min
Rapid travel              0-10m/min (0-20)
MOTORS
Spindle motor              10HP (15)
Tool storage capacity         20:24


GSM 2000S

Features

  • This machine is constructed with heavy-duty Meehanite cast iron to ensure high rigidity, wear resistance, and no deformation.
  • The X, Y and Z axis slideways are coated with Turcite-B to assure smoothness and abrasion resistance.
  • The X, Y, and Z axis adopt high precision double nuts pre-loaded type ball screws.
  • P4-grade precision bearing is adopted for the main spindle.

Specifications

Specifications

Worktable 813x2185 mm
T-slot 18 x 5 x 100 mm
Table load capacity 1800 mm
X axis travel 2000 m/m
Y axis travel 850 m/m
Z axis Travel 710 m/m
Spindle taper BT-40 (CAT-40)
Spindle speed 6000 / Op:(8000, 10000, 12000) rpm
Feed Rate 0-5 m/min
Ballscrew diameter Ø40  m/min
Rapid travel 0-10 (0-20) m/min
Spindle motor     15 (20) HP
Tool storage capacity (20:24)
N.W. 6800 kgs
G.W.     7200 kgs
Packing measurement 342x226x254 cm






GSM 2500S

Features

  • This machine is constructed with heavy-duty Meehanite cast iron to ensure high rigidity, wear resistance, and no deformation.
  • The X, Y and Z axis slideways are coated with Turcite-B to assure smoothness and abrasion resistance.
  • The X, Y, and Z axis adopt high precision double nuts pre-loaded type ball screws.
  • P4-grade precision bearing is adopted for the main spindle.

Specifications

Specifications

Worktable 813x2750 mm
T-slot 18 x 5 x 125 mm
Table load capacity 2000 kgs
X axis travel 2500 m/m
Y axis travel 850 m/m
Z axis Travel 710 m/m
Spindle taper BT-40 (CAT-50 DIN40)
Spindle speed 6000 rpm
Feed Rate 0-10 m/min
Ballscrew diameter Ø50 m/min
Rapid travel 0-10 (0-20) m/min
Spindle motor 20 HP
Tool storage capacity (20;24)
N.W. 9500 kgs
G.W. 10000 kgs
Packing measurement 323x228x254 cm



GSM 3000S

Feature

  • This machine is constructed with heavy-duty Meehanite cast iron to ensure high rigidity, wear resistance, and no deformation.
  • The X, Y and Z axis slideways are coated with Turcite-B to assure smoothness and abrasion resistance.
  • The X, Y, and Z axis adopt high precision double nuts pre-loaded type ball screws.
  • P4-grade precision bearing is adopted for the main spindle.

Specifications

Specifications
