Leadwell

Vertical Machining Centres

V-12iP



  • Linear Way Machining Center
  • Coolant Through Spindle Preparation
  • 48m/min Rapid Traverse
  • Most compact VMC design on the market designed for a multiple machine configuration side by side
  • Designed for shops with minimal floor space doing mass production on tough materials with small workpieces
  • BT40 Spindle Taper
  • Double Screws Precision Ball Screws
  • Base Flushing
  • LED Lighting
  • Front auto door with rodless cylinder
  • Arm Type 24 Position Servo ATC
  • Available with Siemens 828D or Fanuc

Specifications

Specifications

Type Linear way
X-Axis Travel  300mm
Y-Axis Travel 400mm
Z-Axis Travel 510mm
Table size 550x400mm
Spindle nose BT 40
Spindle taper  7/24mm
Spindle speed 12000 rpm
Tool change time 1.8/4
Rapid traverse X/Y/Z  48m/min
Max cutting feed rate 10m/min

V-22i

  • Linear Way Machining Center
  • Siemens 828D Basic or Fanuc control
  • 10000rpm Ceramic Bearing Spindle
  • 8000rpm Steel Bearing Spindle (Optional) or 12000rpm Ceramic Bearing Spindle (Optional)
  • 24 position Servo Arm Type Tool Changer
  • 3C class ball screw/roller bearing linear guide way
  • Rigidity of the table increased on previous series by 50%
  • Six blocks for linear guide way in X axis
  • Coolant and chip separation system
  • Explosion-proof screen windlow
  • User friendly ergonomic design
  • 48m/min Rapid Traverse
  • LED Lighting
  • 4th axis preparation
  • Coolant Through Spindle preparation (Standard)
  • Coolant Through Spindle 25 Bar or 40 Bar Grundfos Pump (Optional)
  • Base Flushing
  • Coolant Gun
  • 11kw Spindle Motor (17/22kw Optional)

Specifications

Specifications

Type  Linear way
X-Axis Travel 510mm
Y-Axis Travel  420mm
Z-Axis Travel 510mm
Table size  600x400mm
Spindle nose No. 40
Spindle bearing inner diameter 60mm
Spindle speed 8000/DDS 10000, 12000, 15000rpm
Tool change time Arm: 2.4 sec
Rapid traverse X/Y/Z   48m/min
Max cutting feed rate 10m/min

V-32i

  • Linear Way Machining Center
  • Siemens 828D Basic or Fanuc control
  • 10000rpm Ceramic Bearing Spindle
  • 8000rpm Steel Bearing Spindle (Optional) or 12000rpm Ceramic Bearing Spindle (Optional)
  • 24 position Servo Arm Type Tool Changer
  • 3C class ball screw/roller bearing linear guide way
  • Rigidity of the table increased on previous series by 50%
  • Six blocks for linear guide way/X axis
  • Coolant and chip separation system
  • Explosion-proof screen windlow
  • User friendly ergonomic design
  • 36m/min Rapid Traverse
  • LED Lighting
  • 4th axis preparation
  • Coolant Through Spindle preparation (Standard)
  • Coolant Through Spindle 25 Bar or 40 Bar Grundfos Pump (Optional)
  • Base Flushing
  • Coolant Gun
  • 11kw Spindle Motor (17/22kw Optional)

Specifications

Specifications

Type Linear way
X-Axis Travel 800mm
Y-Axis Travel 520mm
Z-Axis Travel 610mm
Table size 890x500mm
Spindle nose BT40
Spindle bearing inner diameter 60mm
Spindle speeds 8000/DDS 10000, 12000, 15000rpm
Tool change time Arm: 1.8sec
Rapid traverse X/Y/Z 36m/min
Max cutting feed rate 10m/min

V-42i

  • Linear Way Machiing Center
  • Siemens 828D Basic or Fanuc control
  • 10000rpm Ceramic Bearing Spindle
  • 8000rpm Steel Bearing Spindle (Optional) or 12000rpm Ceramic Bearing Spindle (Optional)
  • 24 position Servo Arm Type Tool Changer
  • 3C class ball screw/roller bearing linear guide way
  • Rigidity of the table increased on previous series by 50%
  • Six blocks for linear guide way/X axis
  • Coolant and chip separation system
  • Explosion-proof screen windlow
  • User friendly ergonomic design
  • 48m/min Rapid Traverse
  • LED Lighting
  • 4th axis preparation
  • Coolant Through Spindle preparation (Standard)
  • Coolant Through Spindle 25 Bar or 40 Bar Grundfos Pump (Optional)
  • Base Flushing
  • Coolant Gun
  • 11kw Spindle Motor (17/22kw Optional)

Specifications

Specifications

Type Linear way
X-Axis Travel 1000mm
Y-Axis Travel 520mm
Z-Axis Travel 610mm
Table size 1100x500mm
Spindle nose No.40
Spindle bearing inner diameter 60mm
Spindle speeds 8000/DDS 10000, 12000, 15000rpm
Tool change time Arm: 1.8sec
Rapid traverse X/Y/Z 36m/min
Max cutting feed rate 10m/min

V-50L

  • Flagship Linear Way Machining Center from Leadwell
  • Siemens 828D or Fanuc control
  • 10000rpm Ceramic Bearing Spindle
  • 8000rpm Steel Bearing Spindle (Optional) or 12000rpm Ceramic Bearing Spindle (Optional)
  • 24 position Servo Arm Type Tool Changer
  • 3C class ball screw/roller bearing linear guide way
  • Rigidity of the table increased on previous series by 50%
  • Six blocks for linear guide way/X axis
  • Coolant and chip separation system
  • Explosion-proof screen windlow
  • User friendly ergonomic design
  • 36 m/min Rapid Traverse
  • LED Lighting
  • 4th axis preparation
  • Coolant Through Spindle preparation (Standard)
  • Coolant Through Spindle 25 Bar or 40 Bar Grundfos Pump (Optional)
  • Base Flushing
  • Coolant Gun
  • 11kw Spindle Motor (17/22kw Optional)

Specifications

Specifications

Type Linear way
X-Axis Travel 1270mm
Y-Axis Travel 635mm
Z-Axis Travel 610mm
Table size 1420x610mm
Spindle nose No.40
Spindle taper 7/24
Spindle bearing inner diameter 70mm
Spindle speeds 8000/DDS 10000, 12000, 15000rpm
Tool change time 1.8/4sec
Rapid traverse X/Y/Z 36m/min
Max cutting feed rate 10m/min

V-60S

  • Cost Effective Linear way machine compared to V-60i due to shorter Y-axis stroke, built on the V-50L frame
  • Ideal for users needing a 1500mm X-axis, who have limited budget
  • Siemens 828D Basic , Siemens 828D or Fanuc control
  • 10000rpm Ceramic Bearing Spindle
  • 8000rpm Steel Bearing Spindle (Optional) or 12000rpm Ceramic Bearing Spindle (Optional)
  • 24 position Servo Arm Type Tool Changer
  • 3C class ball screw/roller bearing linear guide way
  • Rigidity of the table increased on previous series by 50%
  • Six blocks for linear guide way/X axis
  • Coolant and chip separation system
  • Explosion-proof screen windlow
  • User friendly ergonomic design
  • 36 m/min Rapid Traverse
  • LED Lighting
  • 4th axis preparation
  • Coolant Through Spindle preparation (Standard)
  • Coolant Through Spindle 25 Bar or 40 Bar Grundfos Pump (Optional)
  • Base Flushing
  • Coolant Gun
  • 17/22kw Spindle Motor
  • 4:1 ZF Gear box (Optional)

Specifications

Specifications

Type Linear way
X-Axis Travel 1520mm
Y-Axis Travel 635mm
Z-Axis Travel 610mm
Table size 1550x610mm
Spindle nose BT40
Spindle taper 7/24
Spindle bearing inner diameter 70mm
Spindle speeds 8000/DDS 10000, 12000, 15000rpm
Tool change time 1.8/4sec
Rapid traverse X/Y/Z 36m/min
Max cutting feed rate 10m/min

V-80i



  • Largest Linear Way Machining Center
  • Siemens 828D or Fanuc control
  • 10000rpm Ceramic Bearing Spindle
  • 8000rpm Steel Bearing Spindle (Optional) or 12000rpm Ceramic Bearing Spindle (Optional)
  • 30 position Servo Arm Type Tool Changer
  • 3C class ball screw/roller bearing linear guide way
  • Rigidity of the table increased on previous series by 50%
  •
  • Chain Type Chip Conveyer (Option)
  • Explosion-proof screen windlow
  • User friendly ergonomic design
  • 36 m/min Rapid Traverse
  • LED Lighting
  • 4th axis preparation
  • Coolant Through Spindle preparation (Standard)
  • Coolant Through Spindle 25 Bar or 40 Bar Grundfos Pump (Optional)
  • Base Flushing
  • Coolant Gun
  • 11kw Spindle Motor (17/22kw Optional)

Specifications

Specifications

Type Linear way
X-Axis Travel 2040mm
Y-Axis Travel 1000mm
Z-Axis Travel 720mm
Table size 2100x1000mm
Spindle nose No.40
Spindle taper 7/24
Spindle bearing inner diameter 70mm
Spindle speeds 8000/DDS 10000, 12000, 15000rpm
Tool change time 1.8/4sec
Rapid traverse X/Y/Z 24x24x20m/min
Max cutting feed rate 5m/min

MCV-1300iS

  • Heavy-Duty Box Ways
  • Scraper/Chain type chip conveyor (OPT)
  • Cast Iron Construction
  • Rigid Tapping
  • Double Nut Designed Ball Screws
  • Swivel Operator Panel
  • Cartridge Type Spindle
  • Coolant Through Spindle(CTS) Option
  • Spindle Annular Coolant Jet with 8 Nozzles Option
  • Spindle probe Option
  • Machine in Action - Video Clip



Brochure

Brochure

PDF icon MCV-1300Is.pdf

Specifications

Specifications

Type Box way
X-Axis Travel 1300mm
Y-Axis Travel 635mm
Z-Axis Travel 610mm
Table size 1420x610mm
Spindle speeds 4000rpm, 6000rpm
Spindle motor 15/11kw
Tool storage capacity 24

MCV-1500i+

  • Heavy-Duty Box Ways
  • Cast Iron Construction
  • Chip Removal
  • Rigid Tapping
  • Double Nut Designed Ball Screws
  • Swivel Operator Panel
  • Cartridge Type Spindle
  • Side Mounted Tooling System
  • 4th Axis Rotary Table Option
  • High Torque Spindle Option

Specifications

Specifications

Type Box way
X-Axis Travel 1520mm
Y-Axis Travel 1000mm
Z-Axis Travel 720mm
Table size 1500x1000mm
Spindle speeds 4000rpm, 6000rpm opt
Spindle motor 15/11kw
Tool storage capacity 24

MCV2000i

  • Heavy-Duty Box Ways
  • Cast Iron Construction
  • Chip Removal
  • Rigid Tapping
  • Double Nut Designed Ball Screws
  • Swivel Operator Panel
  • Cartridge Type Spindle
  • Side Mounted Tooling System
  • 4th Axis Rotary Table Option
  • High Torque Spindle Option



Specifications

Specifications

Type Box way
X-Axis Travel 2040mm
Y-Axis Travel 1000mm
Z-Axis Travel 720mm
Table size 2100x1000mm
Spindle speeds 4000rpm, 6000rpm opt
Spindle motor 11/15kw
Tool storage capacity 24

V60i

Features:

High Rigidity:

  •  FEA Analysis
  • High rigidity structure design
  • Dual nuts ball screw design in X and Y axis
  • The new wider base and saddle improved machine rigidity
  •  Saddle one piece design

High Reliability:

  • Roller type motion system
  • 3 Axis absolute motor
  • One piece telescope design in rear Y axis
  • Ball screw bearing lubrication system design
  • Front chip disposal system with surrounding coolant system

High Efficiency:

  • Rapid feed rate 48mm
  • Spindle speed 12,000/15,000 rpm(optional)
  • Tool change time T to T 1.8sec
  • Tool change time C to C 4sec

High Flexibility:

  • 30 tools magazine available
  • 4/5 axis rotary table available

Brochure

Specifications

Specifications

X axis travel 1520(59.8) mm
Y axis travel 760(30) mm
Z axis travel 720(28.3) mm
Table size 1550x750(61x29.5) mm
Spindle speed 10000/12000/15000
Spindle motor 15(20) mm
Tool storage capacity 24











V-30iT

This versatile V-30iT features an 8.07 diameter integrated trunnion rotary table that holds a load of up to 35 kgs from 0-45 degrees and 25 kgs in the 60-90 degree range. The rotary tabletop surface is precision ground with 10mm T-slots. The included standard flat worktable measures 300 x 450mm and can be removed for any custom fixture required by the application.

Specifications

Specifications

• Rigid cross roller linear ways in XYZ-axis

• X-axis travel 800mm

• Y-axis travel 460mm

• Z-axis 390mm

• 48m/m rapids in X- and Y-axis

• 36m/m rapids in the Z-axis

V-30iF

Specifications

Specifications

• X-axis travel 800mm
• Y-axis travel 460mm
• Z-axis travel 510mm
• Distance from table(pallet) top to spindle 100-610mm
• Distance from column front to spindle center 510mm
• Table size 860x450mm
• Permissible mass of workpiece 300kg
• Table working surface configuration 18Tx125x3
• Height from floor to table top 832mm
• Spindle speeds 10000min-1

5-Axis Machining Centers

V-20iT

  • Available as 4+1 or 5-axis simultaneous configurations
  • High Torque 17/22kw spindle motor (Siemens)
  • Fully enclosure guarding
  • Auger Type Chip conveyor (Chain Type Opt.)
  • LED Lighting
  • Coolant Gun
  • Coolant Through Spindle 25BAR (Grundfos)
  • Remote MPG with emergency stop
  • Base Flushing System
  • Lubrication system
  • Leveling screws and pads
  • Maintenance tool box
  • 10000rpm spindle (Ceramic Bearing)
  • Options of 8000rpm Steel Bearing , 12000rpm Ceramic Bearing Spindes
  • Available with Siemens 828D, Siemens 840Dsl and Fanuc

Specifications

Specifications

X axis travel 510mm
Y axis travel  350mm
Z axis travel 410+110mm
Table size 600x350mm
Spindle speeds 8000rpm
Spindle motor 11kw

V-40iT

  • Available as 4+1 or 5-axis simultaneous configurations
  • Built-in Trunion Type
  • High Torque 17/22kw spindle motor (Siemens)
  • Fully enclosure guarding
  • Auger Type Chip conveyor (Chain Type Opt.)
  • LED Lighting
  • Coolant Gun
  • Coolant Through Spindle 25BAR (Grundfos)
  • Remote MPG with emergency stop
  • Base Flushing System
  • Lubrication system
  • Leveling screws and pads
  • Maintenance tool box
  • 10000rpm spindle (Ceramic Bearing)
  • Options of 8000rpm Steel Bearing , 12000rpm Ceramic Bearing Spindes
  • Available with Siemens 828D, Siemens 840Dsl and Fanuc

Specifications

Specifications

X Axis Travel 846mm
Y Axis Travel 635mm
Z Axis Travel 438mm
Pallet Size (LXW) 350mm dia
Spindle Speed 10 000rpm
Rapid Traverse 36m/min
Spindle Motor 17/22kw
Automatic Tool Changer Arm
Tool Shank BT-40
Tool Storage Capacity 24

V-60iT

  • Available as 4+1 or 5-axis simultaneous configurations
  • Built-in Trunion Type
  • High Torque 17/22kw spindle motor (Siemens)
  • Fully enclosure guarding
  • Auger Type Chip conveyor (Chain Type Opt.)
  • LED Lighting
  • Coolant Gun
  • Coolant Through Spindle 25BAR (Grundfos)
  • Remote MPG with emergency stop
  • Base Flushing System
  • Lubrication system
  • Leveling screws and pads
  • Maintenance tool box
  • 10000rpm spindle (Ceramic Bearing)
  • Options of 8000rpm Steel Bearing , 12000rpm Ceramic Bearing Spindes
  • Available with Siemens 828D, Siemens 840Dsl and Fanuc

Specifications

Specifications

X axis travel 1270mm
Y axis travel 760mm
Z axis travel 680mm
Table size 630mm
Spindle speed 10000rpm
Spindle motor 26kw
Tool storage capacity 24

V-30iT

The new V-30iT is designed for small multi-sided machine parts typically found in the medical, aerospace & defense industry

The purpose of the 300mm x 450mm work table is to allow the customer to prepare/pre-op the material before putting the part on the trunnion table and/or finishing the part after machining on all five sides.

The aim is to give customer more flexibility to complete a part with less handling.

Specifications

Specifications

X / Y / Z Axis Travel                800x460x387
Table Size (LxW)                     300x400 + 170mm rotary table
Spindle Speeds                       12,000rpm
Spindle Motor (kW)                  11.0
Spindle Motor (HP)                  14.7
Automatic Tool Changer           Arm
Tool Shank                              BT-40
Tool Storage Capacity              24

V-30iF

Specifications

Specifications

• X-axis travel 800mm
• Y-axis travel 460mm
• Z-axis travel 510mm
• Distance from table(pallet) top to spindle 100-610mm
• Distance from column front to spindle center 510mm
• Table size 860x450mm
• Permissible mass of workpiece 300kg
• Table working surface configuration 18Tx125x3
• Height from floor to table top 832mm
• Spindle speeds 10000min-1

Slant Bed Turning Centers

T-5i

  • Available as Gang Type or Turret Type high speed linear way turning center
  • Available with Siemens 828D Basic or Fanuc Oi control systems
  • True One-piece Cast Iron Construction
  • High Precision Cartridge Type Spindle for easy servicing
  • LEADWELL uses only premium quality preloaded double-nut ball screws
  • Available with or without Tailstock
  • C-axis with Live tool turret available as an option
  • Sub-Spindle configuration available as an option
  • High Speed Linear Motion Guides - All servo motor driven axes are mounted on precision linear bearings, which ride on hardened steel ways. These precision guideways require no adjustment, and the servo motors consume less power
  • The automatic tool setter is an option on T/LTC series machines
  • LEADWELL unique parts catcher improves productivity with bar feeder option. It automatically rotates into to position under the finished part and transfers it outside the operator door.
  • LEADWELL offers two options that turn their CNC lathes into make a multi-process turning center. These options provide the benefits of a lathe, plus extra versatility of a machining center.
  • Powerful, compact, mass production turning center with a number of references in South Africa

Brochure

Brochure

PDF icon T-5 New.pdf

Specifications

Specifications

Capacity  330mm
Bar Capacity 35mm
Chuck size 6inch
X axis 230mm
Z axis 105+20mm
Spindle speed 45-4500rpm
Hole through spindle 62mm
Number of tool positions 12
X rapid traverse     20m/min
Z rapid traverse 24m/min
Spindle Motor 15HP

T-6A

  • Most popular size compact Linear Way Turning Center, available with Siemens 828D or Fanuc Oi
  • A2-5 / 52mm Bar Capacity with 6" or 8" chuck
  • True One Piece Cast Iron Construction
  • 36m/min Rapid Traverse
  • Cartridge Type Spindle for easy servicing
  • LEADWELL uses only premium quality preloaded double-nut ball screws
  • The heavy-duty tailstock is attached to the lower guide of the machine base. The heavy casting, large diameter quill and precision Morse taper center provide outstanding rigidity
  • High Speed Linear Motion Guides - All servo motor driven axes are mounted on precision linear bearings, which ride on hardened steel ways. These precision guideways require no adjustment, and the servo motors consume less power
  • The automatic tool setter is an option on T series machines
  • Hydraulic or Servo Type Turret available with 20 x 20mm Tooling
  • LEADWELL unique parts catcher improves productivity with bar feeder option. It automatically rotates into to position under the finished part and transfers it outside the operator door.
  • LEADWELL offers two options that turn their CNC lathes into make a multi-process turning center. These options provide the benefits of a lathe, plus extra versatility of a machining center.
  • Sub-Spindle Option
  • C-axis with Live Tooling Option
  • Available ex-stock (Subject to Prior Sale )

Specifications

Specifications

Max swing 500mm
Bar capacity 51mm
X axis 190+20mm
Z axis 460mm, 460mm
Spindle speeds range 6000rpm
Chuck size 152in

T-7A

  • High Speed, Powerful compact turning center available with Siemens or Fanuc
  • A2-6 / 65mm Bar Capacity with 8" or 10" chuck
  • True One Piece Cast Iron Construction
  • 36m/min Rapid Traverse
  • Cartridge Type Spindle for easy servicing
  • LEADWELL uses only premium quality preloaded double-nut ball screws
  • The heavy-duty tailstock is attached to the lower guide of the machine base. The heavy casting, large diameter quill and precision Morse taper center provide outstanding rigidity
  • High Speed Linear Motion Guides - All servo motor driven axes are mounted on precision linear bearings, which ride on hardened steel ways. These precision guideways require no adjustment, and the servo motors consume less power
  • The automatic tool setter is an option on T series machines
  • Hydraulic or Servo Type turret available with 25 x 25mm Tooling
  • LEADWELL unique parts catcher improves productivity with bar feeder option. It automatically rotates into to position under the finished part and transfers it outside the operator door.
  • LEADWELL offers two options that turn their CNC lathes into make a multi-process turning center. These options provide the benefits of a lathe, plus extra versatility of a machining center.
  • Sub-Spindle Option
  • C-axis with Live Tooling Option
  • Available ex-stock (Subject to Prior Sale )

Specifications

Specifications

Max swing 500mm
Bar capacity 65mm
X axis 190+20mm
Z axis 450mm
Spindle speeds range 4000rpm
Chuck size 203in

T-8XL

  • Largest Linear Way Model from Leadwell with Powerful Motor configuration
  • Available with a 1050mm Turning Length
  • A2-8 / 85mm Bar Capacity with 10" or 12" chuck
  • Option of 101mm Bar Capacity with ZF Gear Box and 1" chuck available
  • True One Piece Cast Iron Construction
  • 36m/min Rapid Traverse
  • Cartridge Type Spindle for easy servicing
  • LEADWELL uses only premium quality preloaded double-nut ball screws
  • The heavy-duty tailstock is attached to the lower guide of the machine base. The heavy casting, large diameter quill and precision Morse taper center provide outstanding rigidity
  • High Speed Linear Motion Guides - All servo motor driven axes are mounted on precision linear bearings, which ride on hardened steel ways. These precision guideways require no adjustment, and the servo motors consume less power
  • The automatic tool setter and programmable Tailstock is an option on T series machines
  • Hydraulic or Servo Type turret
  • LEADWELL unique parts catcher improves productivity with bar feeder option. It automatically rotates into to position under the finished part and transfers it outside the operator door.
  • LEADWELL offers two options that turn their CNC lathes into make a multi-process turning center. These options provide the benefits of a lathe, plus extra versatility of a machining center.
  • Sub-Spindle Option
  • C-axis with Live Tooling Option
  • Available ex-stock (Subject to Prior Sale )

Specifications

Specifications

Max. swing 670mm
Bar capacity 77mm
X axis 225+25mm
Z axis 1050mm
Spindle speeds range 3500rpm
Chuck size 254mm

T-7i

  • High Precision compact turning center available with Siemens or Fanuc
  • A2-6 / 65mm Bar Capacity with 8" or 10" chuck
  • True One Piece Cast Iron Construction
  • Servo Type Turret as standard.
  • 36m/min Rapid Traverse
  • Cartridge Type Spindle for easy servicing
  • LEADWELL uses only premium quality preloaded double-nut ball screws
  • The heavy-duty tailstock is attached to the lower guide of the machine base. The heavy casting, large diameter quill and precision Morse taper center provide outstanding rigidity
  • High Speed Linear Motion Guides - All servo motor driven axes are mounted on precision linear bearings, which ride on hardened steel ways. These precision guideways require no adjustment, and the servo motors consume less power
  • The automatic tool setter is an option on T series machines
  • LEADWELL unique parts catcher improves productivity with bar feeder option. It automatically rotates into to position under the finished part and transfers it outside the operator door.
  • LEADWELL offers two options that turn their CNC lathes into make a multi-process turning center. These options provide the benefits of a lathe, plus extra versatility of a machining center.
  • Sub-Spindle Option
  • C-axis with Live Tooling Option
  • Available ex-stock (Subject to Prior Sale )

Specifications

Specifications

Max swing 520mm
Bar capacity 66mm
X axis 210+10mm
Z axis 540mm
Spindle speeds range 4500rpm
Spindle Chuck size A2-6/8”
Turret 12

LTC-20

  • Heavy Duty Turret - The T/LTC series turret features a robust casting and a large coupling face adding extra rigidity to the machine
  • Cast Iron Construction
  • Cartridge Type Spindle
  • LEADWELL uses only premium quality preloaded double-nut ball screws
  • The heavy-duty tailstock is attached to the lower guide of the machine base. The heavy casting, large diameter quill and precision Morse taper center provide outstanding rigidity
  • High Speed Linear Motion Guides - All servo motor driven axes are mounted on precision linear bearings, which ride on hardened steel ways. These precision guideways require no adjustment, and the servo motors consume less power
  • The automatic tool setter is an option on T/LTC series machines
  • LEADWELL unique parts catcher improves productivity with bar feeder option. It automatically rotates into to position under the finished part and transfers it outside the operator door.
  • LEADWELL offers two options that turn their CNC lathes into make a multi-process turning center. These options provide the benefits of a lathe, plus extra versatility of a machining center.
  • Sub-Spindle Option
  • Live Tooling Option
  • C-Axis Option

Specifications

Specifications

Max swing 450/500/450/540mm
Bar capacity  65/65/65/65mm
X axis 160+10/190+20/160+10/160+20mm
Z axis 540/540/540/540mm
Spindle speeds range 4000/4000/4000/4000mm
Chuck size 8/8/8/8mm

LTC-25

  • Heavy Duty Turret - The T/LTC series turret features a robust casting and a large coupling face adding extra rigidity to the machine
  • Cast Iron Construction
  • Cartridge Type Spindle
  • LEADWELL uses only premium quality preloaded double-nut ball screws
  • The heavy-duty tailstock is attached to the lower guide of the machine base. The heavy casting, large diameter quill and precision Morse taper center provide outstanding rigidity
  • High Speed Linear Motion Guides - All servo motor driven axes are mounted on precision linear bearings, which ride on hardened steel ways. These precision guideways require no adjustment, and the servo motors consume less power
  • The automatic tool setter is an option on T/LTC series machines
  • LEADWELL unique parts catcher improves productivity with bar feeder option. It automatically rotates into to position under the finished part and transfers it outside the operator door.
  • LEADWELL offers two options that turn their CNC lathes into make a multi-process turning center. These options provide the benefits of a lathe, plus extra versatility of a machining center.
  • Sub-Spindle Option
  • Live Tooling Option
  • C-Axis Option

Specifications

Specifications

Max swing     637mm
Bar capacity  77mm
X axis 225+15mm
Z axis 790/1050/1550/2050mm
Spindle speeds range 3500rpm
Chuck size 254mm

LTC-35

  • Heavy Duty Turret - The T/LTC series turret features a robust casting and a large coupling face adding extra rigidity to the machine
  • Cast Iron Construction
  • Cartridge Type Spindle
  • LEADWELL uses only premium quality preloaded double-nut ball screws
  • The heavy-duty tailstock is attached to the lower guide of the machine base. The heavy casting, large diameter quill and precision Morse taper center provide outstanding rigidity
  • High Speed Linear Motion Guides - All servo motor driven axes are mounted on precision linear bearings, which ride on hardened steel ways. These precision guideways require no adjustment, and the servo motors consume less power
  • The automatic tool setter is an option on T/LTC series machines
  • LEADWELL unique parts catcher improves productivity with bar feeder option. It automatically rotates into to position under the finished part and transfers it outside the operator door.
  • LEADWELL offers two options that turn their CNC lathes into make a multi-process turning center. These options provide the benefits of a lathe, plus extra versatility of a machining center.
  • Sub-Spindle Option
  • Live Tooling Option
  • C-Axis Option

Specifications

Specifications

Max. swing 800mm
Bar capacity 115mm
X axis travel  300+20mm/344+10mm/215+25
Z axis travel 1100/1600/2100/3100/4100mm
Spindle speed 2000rpm
Chuck size 382mm

LTC-50

  • Heavy Duty Turret - The T/LTC series turret features a robust casting and a large coupling face adding extra rigidity to the machine
  • Cast Iron Construction
  • Cartridge Type Spindle
  • LEADWELL uses only premium quality preloaded double-nut ball screws
  • The heavy-duty tailstock is attached to the lower guide of the machine base. The heavy casting, large diameter quill and precision Morse taper center provide outstanding rigidity
  • High Speed Linear Motion Guides - All servo motor driven axes are mounted on precision linear bearings, which ride on hardened steel ways. These precision guideways require no adjustment, and the servo motors consume less power
  • The automatic tool setter is an option on T/LTC series machines
  • LEADWELL unique parts catcher improves productivity with bar feeder option. It automatically rotates into to position under the finished part and transfers it outside the operator door.
  • LEADWELL offers two options that turn their CNC lathes into make a multi-process turning center. These options provide the benefits of a lathe, plus extra versatility of a machining center.
  • Sub-Spindle Option
  • Live Tooling Option
  • C-Axis Option

Specifications

Specifications

Max swing 900/900/850/850mm
Bar capacity 117mm
X axis   400+25mm
Z axis 1100/2100/3100/4100mm
Spindle speeds range 1500rpm
Chuck size 381mm/457mm

LTC60

  • Heavy Duty Turret - The T/LTC series turret features a robust casting and a large coupling face adding extra rigidity to the machine
  • Cast Iron Construction
  • Cartridge Type Spindle
  • LEADWELL uses only premium quality preloaded double-nut ball screws
  • The heavy-duty tailstock is attached to the lower guide of the machine base. The heavy casting, large diameter quill and precision Morse taper center provide outstanding rigidity
  • High Speed Linear Motion Guides - All servo motor driven axes are mounted on precision linear bearings, which ride on hardened steel ways. These precision guideways require no adjustment, and the servo motors consume less power
  • The automatic tool setter is an option on T/LTC series machines
  • LEADWELL unique parts catcher improves productivity with bar feeder option. It automatically rotates into to position under the finished part and transfers it outside the operator door.
  • LEADWELL offers two options that turn their CNC lathes into make a multi-process turning center. These options provide the benefits of a lathe, plus extra versatility of a machining center.
  • Sub-Spindle Option
  • Live Tooling Option
  • C-Axis Option

Specifications

Specifications

Max. swing 1020mm
Bar capacity 117mm
X axis travel 400+28/437+18/VDI 60430+25/BMT 75320+10mm
Z axis travel 5000/6000mm
Y axis travel ±100mm
Spindle speed 1500rpm
Chuck size  533mm

Multi Tasking Turning Center

TM 1500

Features

  • The multi-function machine with B-axis can easy have bevel angle drilling and cutting work.
  • The B-axis is driven by DD build-in motor, the best torque is 1200Nm, and with curved coupling it can easy do a heavy cutting job shop work and also curved surface milling.
  • The machine use special Electro Spindle, the spindle speed can reach 12000rpm and torque 103Nm, it is a special machine can do first mill and end mill in the same machine.
  • The Y-axis design is perpendicular type, and match with our moving column machine structure, the Y-axis have complete movement.  It will not have dead space for the travel. (Y-axis travel +/-220mm).(applying for patent now.)
  • 12”chuck (C-axis) + servo tailstock (M.T #5) + 40 tools ATC (Capto C6) + 1550mm Z-axis travel + B-axis (-100°~+140°)=Perfect machine.

Specifications

Specifications

Max. swing                    mm (in)         790(31)
Max. turning diameter     mm (in)         780(30.7)
Bar capacity                  mm (in)     115(4.5)
X/Z/Y axis travel            mm (in)     730+40(28.7+1.57)/1550(61)/±200(7.87)
B axis travel mm (in)      mm (in)     240゜(-10゜~+230゜)
Spindle speed (chuck/electro)    rpm 1500/12000
Chuck size    mm (in)         381(15)
Type of spindle nose     A2-11
Spindle motor power    Kw(hp) 30(40)
Tool storage capacity     40
X/Z/Y axis rapid traverse    m/min(imp) 20/30/20(787.4/1181/787.4)



TW 8

Features

  • Twin Spindle & Turret Turning Center

Specifications

Specifications

Max. swing                mm (in) 290(11.42)
Max. turning diameter mm (in) 290(11.42)
Max. turning length     mm (in) 160(6.3)
X axis travel               mm (in) 145+10(8.86+0.59)
Z axis travel               mm (in) 165(31.1)
Spindle speed             rpm. 4500
Chuck size                 mm (in) 210(8)






About Company

Our clients range from FTSE companies, to large organisations and some small local businesses who are striving to expand.

To see a detailed list of our works and the progress please see our project page.

Cape Town Office

25 Mail Street, Western Province Park, Epping, Cape Town, 7460
+27 21 534 5351
FAX: +27 21 534 3374

Johannesburg Office

Corner of Atlas and Templehof South Road, Bonaero Park, Johannesburg
+27 11 970 7005
FAX: +27 86 678 9360
