Mitsubishi

EDM

EA 8S

EA 8S

The Mitsubishi EA8S Advance features the new M700 series control with a 15” touch screen and FP80S energy saving power supply, reducing electrical consumption by 20% as compared to the previous FP model. The all new Power Master GF2 Adaptive Control reduces graphite electrode wear by as much as 80%. The addition of the new SS Jump 5 optimizes jump up acceleration control to stabilize high speed No-Flush burning.



Brochure

Specifications

Specifications

Machine Travels X x Y x Z 300x250x250mm
Max Dielectric Fluid Level 87 ~ 250mm
Internal Worktank Dimensions  800x520x300mm
Max. Workpiece Weight     551kg
Table Dimensions W x D     500x350mm
Max. Electrode Weight 25kg
Machine System Weight 1996kg
C-Axis Min. Indexing Angle/Drive Unit 0.001 ̊/0.001
C-Axis Range 1 to 30
Table to Platen Distance  150-400mm
Machine Unit Dimensions WxDxH 1530x2000x2106mm
C-Axis Max. Electrode Weight 5kg



EA 12S

Features

  • FP80S Power Supply Provides 80 Peak AMPs
  • Compact Highly-Rigid Machine Design
  • Fixed Table Traveling Column Construction
  • Direct Drive AC Smart Servo System
  • 3 Dimensional Lateral Servo System
  • M700 Series Control w 15” Touch Screen
  • 40GB HD with a 1GB partition for user program storage
  • 3-Sided Drop Tank Work Tank Access
  • Power Master (GF2 Adaptive Control)
  • Fine Finishing with the PS Circuit Standard
  • Easy Access Filter System
  • Dielectric Fluid Emission
  • Auto Lubrication System
  • E.S.P.E.R. Advance  Program Support Functions
  • Fuzzy Pro Plus Hands Off Operation
  • Full 2-yr. Warranty with Triple Diamond Partnership Program

Brochure

,

Brochure

Specifications

Specifications

Machine Travels: X x Y x Z in (mm)     15.7 x 11.8 x 11.8 (400 x 300 x 300)
Max Dielectric Fluid Level: in (mm)     3.1 ~ 15.7 (79 ~ 400)
Power Supply (Option) / Peak Current   80

Internal Worktank Dimensions W x D x H in (mm)

35.4 x 27.5 x 17.7 (900 x 700 x
Max. Workpiece Weight: lb (kg)    2200 (998)
Table Dimensions W x D: in (mm)   27.6 x 19.7 (702 x 500)
Max. Electrode Weight: lb (kg)     110 (50)
Machine System Weight: lb (kg)     7716 (3500)
C-Axis Min. Indexing Angle / Drive Unit     0.001 ̊/ 0.001 ̊
C-Axis RPM Range  1 to 30
Fluid Temp. Control     Chiller
Table to Platen Distance in (mm)     7.9 - 19.7 (201 - 500)
Machine Unit Dimensions W x D x H in (mm)     67.9 x 83.9 x 94.5 (1725 x 2132 x 2400)
Control Unit Graphic Display Function    15" TFT color LCD
Control Unit CPU/type     64-bit / PC



EA12V ADVANCED

Features

  • New High-Speed "V" Power Supply (FP80V STD or FP120V Optional)
  • Compact Highly-Rigid Machine Design
  • Fixed Table Traveling Column Construction
  • Thermal Displacement Compensation Control
  • Direct Drive AC Smart Servo System
  • 3 Dimensional Lateral Servo System
  • All-Axes Linear Glass Scale Feedback
  • M700 Series Control w 15" Touch Screen
  •  Windows XP Operating System
  •  USB and Ethernet Data Inputs Standard
  • 40GB HD with a 1GB partition for user program storage
  • 3-Sided Drop Tank Work Tank Access
  • Easy Access Dual-Filter System
  • Dielectric Fluid Chiller Standard
  • New High-Inertia Style C-Axis
  • Multi-Port Flushing Manaifold
  • Auto Lubrication System
  • E.S.P.E.R. Advance  Program Support Functions
  • Fuzzy Pro Plus Hands Off Operation


Brochure

Specifications

Specifications

Machine Travels: X x Y x Z in (mm)  15.7 x 11.8 x 11.8 (400 x 300 x 300)
Maximum Workpiece Size: W x D x H in (mm)     31.4 x 21.6 x 9.8 (800 x 550 x 250)
Max Dielectric Fluid Level: in (mm)     11.8 (300)
Power Supply (Option) / Peak Current     FP80V (80 Peak) FP120V (120Peak)
Internal Worktank Dimensions W x D x H in (mm)     33.4 x 23.6 x 13.8 (850 x 600 x 350)
Worktank / Door Type     3-Sided Drop Ttank
Max. Workpiece Weight: lb (kg)     1540 (700)
Table Dimensions W x D: in (mm)     27.5 x 19.6 (600 x 450)
Max. Electrode Weight: lb (kg)     110 (50)
Table to C-Axis Chuck Distance Min ~ Max: in (mm)     5.3 ~ 17.1 (135 ~ 435) 3R-MACRO Chuck
Minimum Command Unit / Resolution: in (mm)     .00001 / .000002 (.0001 / .00005)
Rapid Travel Speed: in/min. (mm/min.)     78.7 (2000)

High-Speed Jump Maximum: in/min. (m/min.)

393 (10)
Machine System Dimensions W x D: in (mm)     68.9 x 80.7 (1750 x 2050)
Machine System Weight: lb (kg)     8200 (3725)



EA 28V ADVANCED

Features:

  • New High-Speed "V" Power Supply (FP120V STD or FP80V Optional)
  • Compact Highly-Rigid Machine Design
  • Fixed Table Traveling Column Construction
  • Thermal Displacement Compensation Control
  • Direct Drive AC Smart Servo System
  • 3 Dimensional Lateral Servo System
  • All-Axes Linear Glass Scale Feedback
  • M700 Series Control w 15" Touch Screen
  • Windows XP Operating System
  • USB and Ethernet Data Inputs Standard
  • 40GB HD with a 1GB partition for user program storage
  • 3-Sided Drop Tank Work Tank Access
  • Easy Access Dual-Filter System
  • Dielectric Fluid Chiller Standard
  • New High-Inertia Style C-Axis
  • Multi-Port Flushing Manaifold
  • 36 Position Multi-Step Rise and Fall Worktank
  • Auto Lubrication System
  • E.S.P.E.R. Advance  Program Support Functions
  • Fuzzy Pro Plus Hands Off Operation
  • Full 2-yr. Warranty with Triple Diamond Partnership Program


Brochure

Specifications

Specifications

Machine Travels: X x Y x Z in (mm)     25.6 x 17.7 x 13.8 (650 x 450 x 350)
Maximum Workpiece Size: W x D x H in (mm)     41.3 x 29.9 x 13.8 (1050 x 760 x 350)
Max Dielectric Fluid Level: in (mm)     15.7 (400)
Power Supply (Option) / Peak Current     FP80V (80 Peak) FP120V (120 Peak)
Internal Worktank Dimensions W x D x H in (mm)     43.3 x 31.9 x 17.7 (1100 x 810 x 450)
Worktank / Door Type     3-Sided Drop Ttank
Max. Workpiece Weight: lb (kg)     4400 (2000)
Table Dimensions W x D: in (mm)     33.4 x 23.6 (850 x 600)
Max. Electrode Weight: lb (kg)     440 (200)
Table to C-Axis Chuck Distance Min ~ Max: in (mm)     11.8 ~ 25.6 (300 ~ 650) 3R-MACRO Chuck
Minimum Command Unit / Resolution: in (mm)     .00001 / .000002 (.0001 / .00005)
Rapid Travel Speed: in/min. (mm/min.)     78.7 (2000)
High-Speed Jump Maximum: in/min. (m/min.)     393 (10)
Filter Tank Capacity: gal (L)     157 (595)
Power Requirements [KVA]  200/220 VAC +/- 5% [16.5]



WEDM

MV1200S

MV 1200S (Generally Ex Stock)

• Innovative automatic wire threading-Intelligent AT- Advanced technology for greatly improved productivity
• Improved machining accuracy -Opt Drive System- Next-generation drive system and refined power-supply control technology
• Improved productivity -Precise Finish Circuit- Wide range of technologies for ever-changing working environments
• Easy operation -Natural User Interface- User-friendly features ensure easy operation
• Energy savings, low running cost -Long Life System- Realizing low costs and environment-friendly operation
• ADVANCE PLUS control - Super Digital Control x ADVANCE PLUS control expand the capabilities of electrical-discharge machining



Brochure

Specifications

Specifications

Maximum workpiece dimensions 810x700x215mm
Tolerable workpiece weight 500kg
Table dimensions (W x D) 640x450mm
Each axis stroke (X x Y x Z) 400x300x220mm
Outline dimensions (W x D x H)  2025x2760x2015mm
Machine body weight  2700kg
Work tank door     Manual vertical front door



MV2400S

MV2400S

• Innovative automatic wire threading-Intelligent AT- Advanced technology for greatly improved productivity
• Improved machining accuracy -Opt Drive System- Next-generation drive system and refined power-supply control technology
• Improved productivity -Precise Finish Circuit- Wide range of technologies for ever-changing working environments
• Easy operation -Natural User Interface- User-friendly features ensure easy operation
• Energy savings, low running cost -Long Life System- Realizing low costs and environment-friendly operation



Specifications

Specifications

Machine Travels X x Y x Z  600x400x310mm
Maximum Workpiece Dimensions 1050x820x305mm
Max. Submerged Workpiece Weight 1500kg
Table Dimensions 840x560mm
Table Rapid Feed Speed     1300mm/min
Minimum Drive Unit/Resolution     0.000002/2µin (0.00005/50nm)
Wire Diameter Possible 0.1~0.3mm
Minimum Start Hole Diameter 0.5mm
Machine System Dimensions 2687x3030mm
Machine Installed Height 2150mm
Machine System Weight 3500kg
Fluid System Weight 350kg



MV1200-R

MV 1200-R

Introducing the MV1200-R Advance Plus. The new machine features the M700 series control with a 15-inch touchscreen for easier user interface. Mitsubishi is dedicated to constant innovation and strives to build only the highest quality machines. The MV series features new improvements in machine construction, auto-threading, internal machine communication, power supply technology and operating costs. The MV1200-R also includes a new, non-contact Cylindrical Drive System. The machine's improved features are sure to advance your EDM machining.



Brochure

Specifications

Specifications

Machine Travels X x Y x Z  400x300x220mm
Maximum Workpiece Dimensions 810x700x215mm
Max. Submerged Workpiece Weight 500kg
Table Dimensions 640x540mm
Table Rapid Feed Speed     1300mm/min
Minimum Drive Unit/Resolution 0.000002/2µin (0.00005/50nm)
Wire Diameter Possible 0.1~0.3mm
Minimum Start Hole Diameter 0.5mm
Machine System Dimensions 2025x2702mm
Machine Installed Height 2015mm
Machine System Weight 2700kg



MX 600 ADVANCE TUBULAR

Features

  • Advanced manual control box
  • Oil specialized power supply (nPV power supply)
  • Super finish circuit (nFS circuit)
  • LAN/W • DNC
  • File server connection (FTP)
  • Angle Master (S/W)
  • Anti-virus protection
  • Sleep mode



Brochure

Specifications

Specifications

Travel (X/Y/Z) in mm     300 / 200 / 180
Travel (U/V) in mm     70 / 70
Taper angle (workpiece height) in °/mm    15 / 100
Max. workpiece dimensions (W x D x H) in mm     620 x 610 x 100
Max. workpiece weight in kg     300
Table dimensions (W x D) in mm     560 x 485
Table layout     Hardened 4-side table
Possible wire diameters in mm     0,03–0,20
Wire spool capacity in kg   10
Automatic wire threader     Yes
Overall dimensions (W x D x H) in mm     1970 x 2800x 2100
Machine weight in kg     3400
Mains voltage     3-phase 400 V/AC ± 10 %, 50/60 Hz, 20 kVA
Tank capacity in L 300
Temperature control     Dielectric cooling unit



CNC Controls

M700 Series

M700 Series

Cutting-edge, full-fledged nano-control

  • Nano-interpolation for high-quality machining results
  • Full-fledged nano control for optimum performance
  • High-speed, high-precision die/mold cutting
  • SSS Control for stable machining quality

Increased speed, precision and quality

  • Optimum Machine Response (OMR) control
  • OMR-Feed Forward (FF) control for accurate cutting according to machining commands
  • High-gain Control II improves basic servo system performance
  • M-DDC function reduces synchronized tapping time and increases precision

A wealth of functions to Support intermixed machining needs

  • Synchronization Control (milling)
  • 5-axis machining function (milling)
  • Systems/start point synchronization (turning)
  • Mixed machining command (turning)
  • Milling interpolation (turning)

Enhanced operability reduces set-up time

  • Display of essential information for easy understanding
  • Pop-up Screens for added ease of use
  • Program input error warning function
  • Easy-to-use Menu List display and Help function

Screens developed for optimum ease of use

  • Communication terminals support easy use and high performance
  • Standard PCMCIA slot
  • Advanced-functions model equipped with WindowsXPe
  • USB port
  • Superb environmental performance
  • 17 languages supported
