Sisma

Laser Marking

EASY 200F

Innovative ‘all in one’ laser marking system characterized by a great flexibility of use and equipped with a Z motorized axis at high precision and speed. Machine with a large sight glass and LED internal lighting. Available in 1st class closed version and 4th class open version with six ranges of power: 6W, 10W, 20W, 30W, 40W and 50W.

Brochure

Specifications

Specifications

Average Output Power 6/10/20/40W
Wave Length (nm) 1064/1064/1070/1070
LASER TECHNOLOGY Nd:YAG     or Yb
Repetition Rate Range 20/1-100/2-200/1-1000KHz
Pulse Width 30/35/200/10-240ns
Max Pulse Energy 0,3/0,7/0,8/1,25mj
M2 ≤ 1,8/1,8/1,5/3
Beam spot diameter f160 20/20/20/30μm
Guide Laser Class 2M Red Laser Diode; λ=650 nm; 2mW
Temperature Range Operative 10°C to 35°C
Cooling System Forced-aired cooling
Z axis stroke 290mm
4th axes Optional
Power supply 0,8 KW - 230V 50/60Hz 1ph
Weight and dimensions 85kg, 560x760x850

OEM 12

Features

  • Our new "OEM" and "OEM PLUS" laser series are able to mark and engrave on all types of metal material and most of plastic ones and are equipped with a flexible software especially for creating and marking different types of data, bar codes and matrix data.

Specifications

Specifications

Average Output Power 1070 nm
Laser technology  Yb
Repetition Rate Range 2-1000 KHz
Pulse Width  200ns
Max Pulse Energy  9-250
M2 1.6
Beam spot diameter 16
Guide Laser Class 2M Red Laser Diode =650 nm, 2 mW
Temperature Range  Operative 10 deg to 35 deg, Storing O to 50 deg
Cooling System  Forced- aired cooling
Power Supply  230 V, +/- 10%, 50/60 Hz
Max Power Consumption 800W, 4A
Optical Fiber Length  3m SMA Connector





OEM 20

Features

  • Our new "OEM" and "OEM PLUS" laser series are able to mark and engrave on all types of metal material and most of plastic ones and are equipped with a flexible software especially for creating and marking different types of data, bar codes and matrix data.

Specifications

Specifications

Average Output Power     1070 nm
Laser technology    Yb
Repetition Rate Range     2-200 KHz
Pulse Width  200ns
Max Pulse Energy  0.8
M2 1.5
Beam spot diameter 20
Guide Laser     Class 2M Red Laser Diode =650 nm, 2 mW
Temperature Range      Operative 10 deg to 35 deg, Storing O to 50 deg
Cooling System      Forced- aired cooling
Power Supply      230 V, +/- 10%, 50/60 Hz
Max Power Consumption     800W, 4A
Optical Fiber Length      3m SMA Connector





OEM 40

Features

  • Our new "OEM" and "OEM PLUS" laser series are able to mark and engrave on all types of metal material and most of plastic ones and are equipped with a flexible software especially for creating and marking different types of data, bar codes and matrix data.

Specifications

Specifications

Average Output Power     1070 nm
Laser technology      Yb
Repetition Rate Range     2-1000 KHz
Pulse Width     9-250ns
Max Pulse Energy      1.25
M2 3
Beam spot diameter 30
Guide Laser     Class 2M Red Laser Diode =650 nm, 2 mW
Temperature Range  Operative 10 deg to 35 deg, Storing O to 50 deg
Cooling System      Forced- aired cooling
Power Supply     230 V, +/- 10%, 50/60 Hz
Max Power Consumption     800W, 4A
Optical Fiber Length      3m SMA Connector





LOGO - Diode Marking Laser

Its design is innovative. Its size is compact. It's easy to use and its laser beam is especially focused on metal process: this is LOGO, the ideal laser marking solution for every type of end-user.

Brochure

Specifications

Specifications

Wavelength  1064 nm
Peak Power 20Kw
Pulse Duration 4ns
Working table dimension 200 x 160x180 with lens 100mm
"Z"axis  Manual
Frequency  Fixed
Focus Kit  Included
Dimensions  481 x 446 x 604 mm
Weight 35 Kg



Laser Engraving

BSS 3D (Deep Laser Engraving)

The Sisma Laser System specific for 2D and 3D deep engraving on moulds, punches and electrodes through movement of the laser source on a portal with 3 axes with a range of 350 mm. The centering is done through an high resolution ultra compact camera; working cycles, positioning and programming are managed from the master software.

  • Control: Windows PC with PCI board, RS232 Software SISMA Laser Controller
  • Interface: PLC, data network (ethernet), digitals I/O
  • Software: SLC software for files management marking parameters defining. Accepted extensions SVG, BMP, JPG, HTML, PLT; control system for axis and camera for abject centering, positioning and programming engraving cycles. Entirely developed in SISMA.
  • Options: Rotary axis, dragging system with winder, dynamic measuring device, fumes aspirator, static clamping vice.

Specifications

Specifications

BSS 200F 3D
Wave length 1064nm
Focals F100, F163, F254, F420mm
Working area 600x800x450mm
Repeatibility +/- 0,02mm
Camera    CCD 768(h)x494(V)lines
Cooling system water
Power supply 230V +/- 15% 50/60Hz 1ph
BSS 400F 3D
Wave length Nd:YAG - 1064 nm
Average power 40W
Peak power 12kw
Pulse frequency 1-200 kHz
Working area with focal F160 100x100mm
Laser spot diameter 25µm
Feeding voltage 230V 50/60Hz monofase

Laser Welding

LMD 60

High precision Nd:Yag welding system; easyness of use, reduced maintenance and long lasting duration of the lamp are some of the characteristics of this machine combined with a soft and attractive design.

  • Low Cost 60watt System
  • Absolute guarantee of stability laser beam alignment.
  • Easy of maintenance
  • Colour touch-screen display.
  • 250 storage places for parameters.
  • Supplier of gas protection.
  • Regulator of the cooling air.
  • Deionizing filter supplied as standard.
  • 24 months warranty (flash lamp included)

Brochure

Specifications

Specifications



Power supply 230V 50/60Hz
Average Power 60W
Peak Pulse Power 7,5kw
Pulse Energy 90J
Pulse Duration 0,3-30ms
Pulse Frequency 0-20Hz
Welding Spot Diameter    0,2 ÷ 2mm
Focus Adjustment Motorized
Pulse Shape 7 pre-set
Programming memory    Up to 250
Stereo Microscope LEICA
Chamber Illumination LED



SWA150 & SWA 300

The SWA150/300 is laser welding and mould repair machine for welding with and without electronic solder in moulds, resistances, thermocouples and micro parts. All welding units are equipped with generators laser characterized by great optics reliability and optimum homogeneity of the welding point.

The SWA150/300 enables the repair in particularly difficult areas and enables welding close to showing high-quality functions. The SWA model is a laser class IV suitable for repair of large pieces. The machine is equipped with optical head with sustained by a spherical node microscope which allows easily the inclination of the beam of laser depending on the shape of parts to repair. Easy and multiple regulations allow the maximum flexibility of work.

Brochure

Brochure

PDF icon 5.swa150.pdf

Specifications

Specifications

Model SWA 150
Average power 150W
Peak power 10.5kw
Pulse energy 70J
Focusing optics 120mm
Moving speed 0-20 mm/s
X axis stroke 300mm
Y axis stroke 150mm
Z axis stroke 500mm
Model SWA300
Average power 300W
Peak power 12kw
Pulse energy 100J
Pulse frequency 0-50Hz
Focusing optics 120mm
Moving speed 0-20mm/s
X axis stroke 300mm
Y axis stroke 150mm
Z axis stroke 500mm
