TLE-30FS Injection Moulding Machine

• Double cylinder balance injection system
• Back pressure adjustment device
• Multi stage pressure and speed injection
• High speed clamping
• Low pressure mould protection
• Double core pulling and inserting
• Multiple hydraulic ejector knock-out
• Mechanical electrical safety device
• Lubrication system
• TLE series offers Multiple options of computer CPU system
• Moulding data memory system
• Northman hydraulic valve
• Yestone servo motor
• Hopper dryer, auto loader and robot  for part or sprue (option)
• Phase motion control Ultract hydraulic drive

Specifications

Specifications

Screw Diameter 25mm
Shot Volume (Theoretical) 40cm3
Injection Weight (PS) 37g
Injection Rate 46g/s
Injection Pressure 212Mpa
Screw Speed 0-250r/min
Clamping Unit Clamping Tonnage 300KN
Toggle Stroke 240mm
Space Between Tie Bars 280*260mm
Max. mould Height 290mm
Min. mould Height 100mm
Ejector Stroke 61mm
Ejector Tonnage 27KN
Max Pump Pressure 14Mpa
Pump Motor Power 11KW
Heater Power 3.2   KW
Machine Dimension (LxWxH) 1.65x0.96x1.4m
Machine Weight 1.4T

TLE-50FS Injection Moulding Machine

• Double cylinder balance injection system
• Back pressure adjustment device
• Multi stage pressure and speed injection
• High speed clamping
• Low pressure mould protection
• Double core pulling and inserting
• Multiple hydraulic ejector knock-out
• Mechanical electrical safety device
• Lubrication system
• TLE series offers Multiple options of computer CPU system
• Moulding data memory system
• Northman hydraulic valve
• Yestone servo motor
• Hopper dryer, auto loader and robot  for part or sprue (option)
• Phase motion control Ultract hydraulic drive

Specifications

Specifications

Screw Diameter 30mm
Shot Volume  75cm3
Injection Weight (PS) 68g
Injection Rate 82g/s
Injection Pressure 213Mpa
Screw Speed 0-320r/min
Clamping Tonnage 500KN
Toggle Stroke 280mm
Space Between Tie Bars 308*308mm
Max.mould Height 320mm
Min.mould Height 120mm
Ejector Stroke 70mm
Ejector Tonnage 27.5mm
Max Pump Pressure 16Mpa
Pump Motor Power 11KW
Heater Power 3.6KW
Machine Dimension (LxWxH) 3.2x1.31x1.8m
Machine Weight 2.3T

TLE-100FS Injection Moulding Machine

• Double cylinder balance injection system
• Back pressure adjustment device
• Multi stage pressure and speed injection
• High speed clamping
• Low pressure mould protection
• Double core pulling and inserting
• Multiple hydraulic ejector knock-out
• Mechanical electrical safety device
• Lubrication system
• TLE series offers Multiple options of computer CPU system
• Moulding data memory system
• Northman hydraulic valve
• Yestone servo motor
• Hopper dryer, auto loader and robot  for part or sprue (option)
• Phase motion control Ultract hydraulic drive

Specifications

Specifications

Screw Diameter 38mm
Shot Volume (Theoretical) 187cm3
Injection Weight (PS) 68g
Injection Rate 170g/s
Injection Pressure 186Mpa
Screw Speed 0-250r/min
Clamping Tonnage 1000KN
Toggle Stroke 285mm
Space Between Tie Bars 355*315mm
Max.mould Height 370mm
Min.mould Height 125mm
Ejector Stroke 85mm
Ejector Tonnage 33KN Max
Pump Pressure 16Mpa
Pump Motor Power 15KW
Heater Power 5.5KW
Machine Dimension (LxWxH) 4x1.4x1.9m
Machine Weight 3T

TLE-120FS Injection Moulding Machine

• Double cylinder balance injection system
• Back pressure adjustment device
• Multi stage pressure and speed injection
• High speed clamping
• Low pressure mould protection
• Double core pulling and inserting
• Multiple hydraulic ejector knock-out
• Mechanical electrical safety device
• Lubrication system
• TLE series offers Multiple options of computer CPU system
• Moulding data memory system
• Northman hydraulic valve
• Yestone servo motor
• Hopper dryer, auto loader and robot  for part or sprue (option)
• Phase motion control Ultract hydraulic drive

Specifications

Specifications

Screw Diameter 40mm
Shot Volume (Theoretical) 187cm3
Injection Weight (PS) 170g
Injection Rate 138g/s
Injection Pressure 201Mpa
Screw Speed 0-360r/min
Clamping Tonnage 1200KN
Toggle Stroke 380mm
Space Between Tie Bars 385*350mm
Max.mould Height 410mm
Min.mould Height 150mm
Ejector Stroke 85m
Ejector Tonnage 33KN
Max Pump Pressure 16Mpa
Pump Motor Power 18KW
Heater Power 7.2KW
Machine Dimension (LxWxH) 4x1.43x1.9m
Machine Weight 3.5T

TLE-130FS Injection Moulding Machine

• Double cylinder balance injection system
• Back pressure adjustment device
• Multi stage pressure and speed injection
• High speed clamping
• Low pressure mould protection
• Double core pulling and inserting
• Multiple hydraulic ejector knock-out
• Mechanical electrical safety device
• Lubrication system
• TLE series offers Multiple options of computer CPU system
• Moulding data memory system
• Northman hydraulic valve
• Yestone servo motor
• Hopper dryer, auto loader and robot  for part or sprue (option)
• Phase motion control Ultract hydraulic drive

Specifications

Specifications

Screw Diameter 42mm
Shot Volume (Theoretical) 259cm3
Injection Weight (PS) 235g
Injection Rate 152g/s
Injection Pressure 182Mpa
Screw Speed 0-315r/min
Clamping Unit Clamping Tonnage 1300KN
Toggle Stroke 380mm
Space Between Tie Bars 415*415mm
Max.mould Height  450mm
Min.mould Height 150mm
Ejector Stroke 130mm
Ejector Tonnage 33KN
Max Pump Pressure 16Mpa
Pump Motor Power  18KW
Heater Power  7.5KW
Machine Dimension (LxWxH) 4.5x1.48x1.9m
Machine Weight 4.2T

TLE-150FS Injection Moulding Machine

• Double cylinder balance injection system
• Back pressure adjustment device
• Multi stage pressure and speed injection
• High speed clamping
• Low pressure mould protection
• Double core pulling and inserting
• Multiple hydraulic ejector knock-out
• Mechanical electrical safety device
• Lubrication system
• TLE series offers Multiple options of computer CPU system
• Moulding data memory system
• Northman hydraulic valve
• Yestone servo motor
• Hopper dryer, auto loader and robot  for part or sprue (option)
• Phase motion control Ultract hydraulic drive

Specifications

Specifications

Screw Diameter 45mm
Shot Volume (Theoretical) 297cm3
Injection Weight (PS) 270g
Injection Rate 221g/s
Injection Pressure 159Mpa
Screw Speed 0-400r/min
Clamping Tonnage 1500KN
Toggle Stroke 435mm
Space Between Tie Bars 460*460mm
Max.mould Height 500mm
Min.mould Height 180mm
Ejector Stroke 152mm
Ejector Tonnage 40KN
Max Pump Pressure 16Mpa
Pump Motor Power 22KW
Heater Power 7.5KW
Machine Dimension (LxWxH)  4.9x1.52x1.9m
Machine Weight 5.2T

TLE-170FS Injection Moulding Machine

• Double cylinder balance injection system
• Back pressure adjustment device
• Multi stage pressure and speed injection
• High speed clamping
• Low pressure mould protection
• Double core pulling and inserting
• Multiple hydraulic ejector knock-out
• Mechanical electrical safety device
• Lubrication system
• TLE series offers Multiple options of computer CPU system
• Moulding data memory system
• Northman hydraulic valve
• Yestone servo motor
• Hopper dryer, auto loader and robot  for part or sprue (option)
• Phase motion control Ultract hydraulic drive

Specifications

Specifications

Screw Diameter 50mm
Shot Volume (Theoretical) 392cm3
Injection Weight (PS) 357g
Injection Rate 246g/s
Injection Pressure 143Mpa
Screw Speed 0-320r/min
Clamping Tonnage 1700KN
Toggle Stroke 435mm
Space Between Tie Bars 460*460mm
Max.mould Height 500mm
Min.mould Height 180mm
Ejector Stroke 152mm
Ejector Tonnage 40KN
Max Pump Pressure 16Mpa
Pump Motor Power 22KW
Heater Power 9.7KW
Machine Dimension (LxWxH) 5.1x1.52x2.1m
Machine Weight 5.5T

TLE-220FS Injection Moulding Machine

• Double cylinder balance injection system
• Back pressure adjustment device
• Multi stage pressure and speed injection
• High speed clamping
• Low pressure mould protection
• Double core pulling and inserting
• Multiple hydraulic ejector knock-out
• Mechanical electrical safety device
• Lubrication system
• TLE series offers Multiple options of computer CPU system
• Moulding data memory system
• Northman hydraulic valve
• Yestone servo motor
• Hopper dryer, auto loader and robot  for part or sprue (option)
• Phase motion control Ultract hydraulic drive

Specifications

Specifications

Screw Diameter 55mm
Shot Volume (Theoretical) 522cm3
Injection Weight (PS) 475g
Injection Rate 289g/s
Injection Pressure 152Mpa
Screw Speed 0-286r/min
Clamping Tonnage 2200KN
Toggle Stroke 480mm
Space Between Tie Bars 520*520mm
Max.mould Height 560mm
Min.mould Height 200mm
Ejector Stroke 150mm
Ejector Tonnage 62KN
Max Pump Pressure 16Mpa
Pump Motor Power 30KW
Heater Power 11.1KW
Machine Dimension (LxWxH) 5.6x1.63x2.2m
Machine Weight 6.8T

TLE-280FS Injection Moulding Machine

• Double cylinder balance injection system
• Back pressure adjustment device
• Multi stage pressure and speed injection
• High speed clamping
• Low pressure mould protection
• Double core pulling and inserting
• Multiple hydraulic ejector knock-out
• Mechanical electrical safety device
• Lubrication system
• TLE series offers Multiple options of computer CPU system
• Moulding data memory system
• Northman hydraulic valve
• Yestone servo motor
• Hopper dryer, auto loader and robot  for part or sprue (option)
• Phase motion control Ultract hydraulic drive

Specifications

Specifications

Screw Diameter 65mm
Shot Volume (Theoretical) 895cm3
Injection Weight (PS) 814g
Injection Rate 385g/s
Injection Pressure 143Mpa
Screw Speed 0-250r/min
Clamping Tonnage 2800KN
Toggle Stroke 550mm
Space Between Tie Bars 580*560mm
Max.mould Height 610mm
Min.mould Height 220mm
Ejector Stroke 140mm
Ejector Tonnage 62KN
Max Pump Pressure 16Mpa
Pump Motor Power 37KW
Heater Power 15.6KW
Machine Dimension (LxWxH) 5.8x1.76x2.2m
Machine Weight 8T

TLE-320FS Injection Moulding Machine

• Double cylinder balance injection system
• Back pressure adjustment device
• Multi stage pressure and speed injection
• High speed clamping
• Low pressure mould protection
• Double core pulling and inserting
• Multiple hydraulic ejector knock-out
• Mechanical electrical safety device
• Lubrication system
• TLE series offers Multiple options of computer CPU system
• Moulding data memory system
• Northman hydraulic valve
• Yestone servo motor
• Hopper dryer, auto loader and robot  for part or sprue (option)
• Phase motion control Ultract hydraulic drive

Specifications

Specifications

Screw Diameter 65mm
Shot Volume (Theoretical) 895cm3
Injection Weight (PS) 814g
Injection Rate 385g/s
Injection Pressure 143Mpa
Screw Speed 0-250r/min
Clamping Tonnage 3200KN
Toggle Stroke 585mm
Space Between Tie Bars 660*640mm
Max.mould Height 710mm
Min.mould Height 220mm
Ejector Stroke 125mm
Ejector Tonnage 62KN
Max Pump Pressure 16Mpa
Pump Motor Power 37KW
Heater Power 15.6KW
Machine Dimension (LxWxH) 6.3x2x2.4m
Machine Weight 11.5T

TLE-360FS Injection Moulding Machine

• Double cylinder balance injection system
• Back pressure adjustment device
• Multi stage pressure and speed injection
• High speed clamping
• Low pressure mould protection
• Double core pulling and inserting
• Multiple hydraulic ejector knock-out
• Mechanical electrical safety device
• Lubrication system
• TLE series offers Multiple options of computer CPU system
• Moulding data memory system
• Northman hydraulic valve
• Yestone servo motor
• Hopper dryer, auto loader and robot  for part or sprue (option)
• Phase motion control Ultract hydraulic drive

Specifications

Specifications

Screw Diameter 68mm
Shot Volume (Theoretical) 1161cm3
Injection Weight (PS) 1057g
Injection Rate 448g/s
Injection Pressure 185Mpa
Screw Speed 0-289r/min
Clamping Tonnage 3600KN
Toggle Stroke 585mm
Space Between Tie Bars 660*640mm
Max.mould Height 710mm
Min.mould Height 220mm
Ejector Stroke 125mm
Ejector Tonnage 62KN
Max Pump Pressure 16Mpa
Pump Motor Power 37+18KW
Heater Power 17.3KW
Machine Dimension (LxWxH) 6.8x1.8x2.6m
Machine Weight 12.5T

About Company

Our clients range from FTSE companies, to large organisations and some small local businesses who are striving to expand.

To see a detailed list of our works and the progress please see our project page.

Cape Town Office

25 Mail Street, Western Province Park, Epping, Cape Town, 7460
+27 21 534 5351
FAX: +27 21 534 3374

Johannesburg Office

Corner of Atlas and Templehof South Road, Bonaero Park, Johannesburg
+27 11 970 7005
FAX: +27 86 678 9360
