WD Hearn

Geared Head

Z3050

Z3050

Specifications

Specifications

Max Drilling Capacity 35mm
Max Thread Cutting M24
Quill Stroke 150mm
Spindle to Column Distance 330mm
Max Spindle to Table Distance 630mm
Max Spindle to Foot Distance 1200mm
Max Adjustment of Work Table and Table Rest 520mm
Swivel of Table 45 degrees
Spindle Bore Taper MT4
Spindle Speeds 70-2600RPM
Feed Range 0.1, 0.2, 0.3mm/rev
Effective Table 450x390mm
Base Plate Dimensions 405x395mm
Two-Speed Main Motor 1.5Kw-960rpm/2.2Kw-1450rpm
Column Diameter 140mm
Weight approximately 600Kg



Z5050

Z5050

Specifications

Specifications

Drilling capacity    50mm
Tapping capacity M30
Diameter of column 160mm
Spindle travel 240mm
Distance spindle axis to column 360mm
Max.Distance spindle nose to table 600mm
Max.Distance spindle nose to base 1200mm
Spindle taper MT4
Spindle speed range 2460rpm
Number of spindle speeds 12
Spindle feeds 4
Feed rates mm/rev 0.1, 0.2, 0.3, 0.4
Dimension of worktable surface 510×380mm
Max. travel of worktable 420mm
Dimension of base 450×440mm
Power of Main motor - 2 speed 2.2/2.8 Kw
Net Weight 690kg



Belt Drive

CH18

CH18

Specifications

Specifications



Max. Drilling Capacity 16mm
Spindle Taper MT2
Chuck 16mm
Max. Spindle Stroke 82mm
Swing 430mm
Number of Speeds 12
Speed Range 280-2300
Max. Distance Sp. - Table 775mm
Max. Distance Sp. – Base 1270mm
Diameter of Column 80mm
Size of Table 350mm
Size of Base 470x270mm
Overall Height 1625mm
Motor ½hp
Net Weight 75kg



CH25

CH25

Specifications

Specifications





Max. Drilling Capacity 25mm(32mm)
Spindle Taper MT3(MT4)
Chuck 16mm(16mm)
Max. Spindle Stroke 122mm(122mm)
Swing 535mm(535mm)
Number of Speeds 12(12)
Speed Range 150-3490rpm (150-3490)
Max. Distance Sp. - Table 720mm(720)
Max. Distance Sp. – Base 1230mm(1230)
Diameter of Column 92mm(92mm)
Size of Table 473x410mm(473x410)
Size of Base 572x495mm(572x495)
Overall Height 1778mm(1780mm)
Motor 1hp 220v (1hp 380v)
Net Weight 157kg(168kg)
