Bridgecenter-12G

CNC Bridge Type

Bridgecenter-12G

Table Size: 1,370 x 3,500mm
Travel (X, Y, Z): 3,050 x 1,615 x 800mm
Spindle Taper: NST No. 50
Spindle Speed: 35~12,000rpm Gear Drive, 4-Step
Tool Storage Capacity: 40 Pcs. (60, 80 Opt.)
Tool Change Time (T-T/C-C): 6.6 Sec. /15 Sec.
Rapid Feed (X, Y, Z): 24m/min
Power Requirement: 50KVA

Features

• 120" extended X-Axis stroke offers flexibility in large part processing that requires increased levels of rigidity and higher levels of precision and accuracy.

• Positioning Accuracy: ±0.000078” Full Stroke, Repeatability: ±0.000039”

• Rigid Meehanite cast iron construction with induction hardened solid box ways

• #50, Gear Driven, High Speed, High Torque 12,000rpm Dual Contact Spindle

• Patented double column bridge type design provides expansive work envelope and superior rigidity

• Linear scale feedback in X, Y, Z axes

• A unique optional 5-axis articulating head can be incorporated for multi angle, complex part machining made easy

• 13,300 Lb table capacity provides added benefits for larger, heavier, more powerful machining
