Centerless Grinding

FCL12

Features

  • Rigid Machine Structure
  • Hydraulic Cooling Device
  • Pressure Switch
  • Lubrication System
  • Slide Table
  • Hydraulically operated dressing motion.
  • Variable dressing speed.
  • Lubrication Oil Recycle
  • Stable Grinding Wheel Auto Dressing Unit

Specifications

Specifications

Standard grinding rajnge (Dia.) Ø1 ~ Ø40 mm
Capacity increases with special arrangement Ø30 ~ Ø60 mm
Grinding wheel sie (O.D. x width x I.D.) Ø305 x 150 x Ø120
Grinding wheel speed     1900 R.P.M.
Grinding wheel motor     7 1/2HP x 4P
Regulating wheel size (O.D. x width x I.D.)     Ø205 x 150 x Ø90
Regulating wheel speed     10 ~ 300 R.P.M. (Variable)
Regulating wheel motor     1.5 KW servo motor
Regulating wheel tilt angle     +5° ~ -3°
Regulating wheel swivel angle     ±5°
Hydraulic pump motor     1HP x 4P
Net weight     1700 kgs
Gross weight     2000 kgs



FCL20

Feature

  • Rigid Machine Structure
  • Hydraulic Cooling Device
  • Pressure Switch
  • Lubrication System
  • Slide Table
  • Hydraulically operated dressing motion.
  • Variable dressing speed.
  • Lubrication Oil Recycle

Specifications

Specifications

Standardgrinding range(Dia.)     Ø1~Ø60mm
Capacity increases with special arrangement     Ø40~Ø150mm
Grinding whell size(O.D. x width x I.D.)     Ø510x205xØ304.8
Grinding wheel speed     1200rpm
Grinding wheel motor     20HP x 4P
Regulating Wheel size(O.D. x width x I.D.)     Ø305x205xØ127
Regulating wheel speed     10~300rpm(Variable)
Regulating wheel motor     3.5KW servo motor
Net weight     3700kgs
Gross weight    4000kgs



FCL1810

Features

  • Rigid Machine Structure
  • Hydraulic Cooling Device
  • Pressure Switch
  • Lubrication System
  • Slide Table
  • Hydraulically operated dressing motion.
  • Variable dressing speed.
  • Lubrication Oil Recycle
  • Stable Grinding Wheel Auto Dressing Unit

Specifications

Specifications

Standardgrinding range(Dia.)     Ø1~Ø60mm
Capacity increases with special arrangement     Ø40~Ø150mm
Grinding whell size(O.D. x width x I.D.)     Ø455x205xØ228.6
Grinding wheel speed     1500rpm
Grinding wheel motor     15HP x 4P
Regulating Wheel size(O.D. x width x I.D.)     Ø255x255xØ111.2
Regulating wheel speed     10~300rpm(Variable)
Regulating wheel motor     3.5KW servo motor
Net weight     3000kgs
Gross weight    3300kgs
