EDM Drills

The perfect complement to the wire-cutting systems from Mitsubishi Electric. The start EDM drilling systems not only master small dimensions on start holes with 0.3–3.0 mm ­electrodes, but also functional bores. The manual version offers comfortable operation during manual positioning, while the CNC version also masters a large number of holes in a single sweep.

Mitsubishi 43Z Start Hole EDM Drilling Machine (ZNC)

The perfect complement to the wire-cutting systems from Mitsubishi Electric. The start EDM drilling systems not only master small dimensions on start holes with 0.3–3.0 mm ­electrodes, but also functional bores. The manual version offers comfortable operation during manual positioning, while the CNC version also masters a large number of holes in a single sweep.

An EDM drilling system simply has to get the job done – and must not distract from important tasks. The start series is therefore designed to bring the user quickly and simply to his goal. Speed and simplicity are also all-important as far as maintenance and organisation are concerned – everything is readily accessible and accommodated immediately in the machine. Even electrode tubes and guides can be stored within the machine. Everything within easy reach.

The generator is designed for low-wear operation without compromising on performance. Micro Discharge Technology makes it possible. Drilling technology for a variety of tasks is available in the technology database. For exotic materials, technologies can be modified and stored at any time – in-built flexibility.

Automatic positioning measurement is a convenient function of the CNC-controlled version.

Further important automatic functions of the machines:
· Electrode wear compensation
· Z axis retraction function
· Depth calculation for blind holes

Ergonomic fixed table

Good accessibility permits convenient and swift set-up. The tidy, granite-based work area is designed and optimised for easy workpiece clamping. Furthermore, the fixed table makes the machine compact and permits loading with heavier workpieces.

Solid base, high-grade guides and spindles – in the service of precision

The machine base is solidly designed. The granite stiffening components and high-grade linear guides are an assurance of durability and long-term accu­racy. The granite base of the work table also prevents accidental drilling into the table.

Position automatically

... by CNC command. The drilling position can be manually entered on the screen or conveniently adopted from external sources. You can either read in a positioning table or adopt the drilling position from an already loaded DXF file – the choice is yours. Incidentally, the interfaces for data transfer are already available: USB or TCP / IP, serving all commonly used standards.

Direct selection from DXF

A convenient way to select the position: the DXF of a component being machined is read in and the drilling points are adopted directly from the graphics. It could hardly be simpler!

Specifications

Specifications

Machine                            Start 43Z                    Start 43C                 Start 64C

Table dimensions               910 x 650                    920 x 680                 1100 x 720
Travel (X / Y)                      400 / 300                     450 / 300                  650 / 400
Travel Z                             400mm                        400mm                     400mm
Travel W                            345mm                        345mm                     345mm
Possible electrode dia       0,3–3,0                        0,3–3,0                     0,3–3,0
Max. electrode length        400mm                        400mm                     400mm
Max. workpiece height       350mm                        350mm                     350mm
Max. workpiece weight      200kg                           500kg                       500kg
Machine weight                  680kg                          1140kg                      1350kg

Mitsubishi 43C Start Hole EDM Drilling Machine (CNC)

The YGS-43C CNC EDM small hole drill is one of the easiest CNC EDM drills to operate. Available with or without an AEC (Automatic Electrode Changer), this EDM drill is extremely easy to program. Working with “G” codes, your program is generated at your desktop or laptop computer, converted to a DXP file then down loaded to the EDM small hole drill via flash drive or CD. The Windows 7 operating system makes it easy to maneuver through the different screens on the Yougar YGS-43C EDM machine. The built-in closed loop water filtration system on the YGS-43C EDM small hole drill makes this machine both compact and self-contained. The Yougar EDM drills come standard with the work piece rail system, cutting down on the cost of expensive work piece holding devices.

- Windows 7 Operating System
- 20 Position Electrode Changer (AEC only)
- Download Programs via Thumb Drive, Ethernet or C/D
- Built-In Closed Loop D/I, Filtration System
- E-Pack Storage w/Library of Settings
- Multiple Work Piece Set-Up
- Blind Hole Feature
- Soft Power Start-Up
- Automatic Work Piece Pick-Up (Inside, Outside, Corner)
- Hole Elimination Feature
- Programmable "W" Axis
- On Screen Editing Feature
- Rapid "Z" Axis Start-Up
- Rail System Work Piece Holder
- Granite Work Table
- Heavy Weight Capacity (1,200 lbs)
- 2 Year Warranty on Parts & 1 Year Warranty on Labor

Specifications

Specifications

Machine                            Start 43Z                    Start 43C                 Start 64C

Table dimensions               910 x 650                    920 x 680                 1100 x 720
Travel (X / Y)                      400 / 300                     450 / 300                  650 / 400
Travel Z                             400mm                        400mm                     400mm
Travel W                            345mm                        345mm                     345mm
Possible electrode dia       0,3–3,0                        0,3–3,0                     0,3–3,0
Max. electrode length        400mm                        400mm                     400mm
Max. workpiece height       350mm                        350mm                     350mm
Max. workpiece weight      200kg                           500kg                       500kg
Machine weight                  680kg                          1140kg                      1350kg
