Lathes

CDL 6241 (Entry Level Lathe - Generally Ex Stock)

Features

  • 3-jaw chuck
  • Steady rest
  • Follow rest
  • Center tools
  • Face plate
  • Drive plate
  • Toolpost guard
  • Chuck guard
  • Full splash guard
  • Oil gun
  • Foundation bolts
  • Toot brake.

Brochure

Specifications

Specifications



Max.Swing over bed 410mm
Max.Swing over carriage 230mm
Max. Swing in gap 640mm
Max.Length of workpiece 750 / 1000 / 1500mm
Spindle speed 32-2000rpm
Spindle bore 52mm
Maximum spindle motor power    3/4.5kw
Tailstock quill diameter    60mm
Tailstock quill taper No 4 MT
Tailstock quill travel 150mm

CDL 6251

Features

  • 3-jaw chuck
  • Steady rest
  • Center tools
  • Face plate
  • Drive plate
  • Toolpost guard
  • Chuck guard
  • Full splash guard
  • Oil gun
  • Foundation bolts
  • Toot brake.

Brochure

Specifications

Specifications

Max.Swing over bed 510mm
Max.Swing over carriage 320mm
Max. Swing in gap 735mm
Max. Length of workpiece 750 / 1000 / 1500mm
Spindle speed 16-1600rpm
Spindle bore 82mm
Maximum spindle motor power 5.5kw
Tailstock quill diameter 60mm
Tailstock quill taper No 4 MT
Tailstock quill travel 150mm

CDS 6266C (Heavy Duty Lathe)

Features

  • 3-jaw chuck
  • Steady rest
  • Follow rest
  • Center tools
  • Face plate
  • Drive plate
  • Toolpost guard
  • Chuck guard
  • Full splash guard
  • Oil gun
  • Foundation bolts
  • Tool brake.



Brochure

Specifications

Specifications

Swing over bed 660mm
Swing over cross slide 440mm
Swing in gap 870mm
Gap length 250mm
Dist. centers 1000/1500/2000/3000
Spindle bore 105mm
Taper of spindle bore 110/120mm
Spindle nose D8
No.of Spindle speed 16
Spindle speed ranges 26-1700rpm
Max spindle motor power 7.5kW(10HP)
Width over bedways 394mm
Cross slide travel - X axis 355mm
Travel of top slide 150mm
Max.dimension of tool shank 25×25mm
Range of Imperial Pitches 16-80TPI
Range of Diametral Pitches 8-160DP
Range of Metric Pitches 0.35-80mm
Range of Module Pitches 0.2-40MOD
Tailstock quill diameter 75mm
Tailstock quill taper No 5 MT
Tailstock quill travel 150mm
CW62100 X 5000mm heavy duty lathe

CW series

Features

  • Heavy Duty Machine for long turning lengths
  • Precision Ground Bed Ways
  • Fully Encloded Feedbox
  • 3-jaw chuck
  • Steady rest
  • Center tools
  • Face plate
  • Drive plate
  • Toolpost guard
  • Chuck guard
  • Full splash guard
  • Foot brake.

Brochure

Specifications

Specifications

Max. swing over bed 1000mm
Max. swing over carriage 720mm
Center distance    750mm/1000mm/1500mm/2000mm
  3000mm/4000mm/5000mm/6000mm
Width of gap 320mm
Swing over gap 1230mm
Width of guide way 550mm
Spindle bore diameter 130mm
Spindle speed (18 speeds) 7.5~1000rpm
Longitudinal feed (64) 0.1~24.3mm/r
Cross feed (64) 0.05~12.15mm/r
Rapid traverse speed 3.8m/min
Metric thread (39)1~240mm
Inch thread (26) 14~1TPI
Module thread (53) 0.5~120mm
Diametrical pitch thread (24) 28~1
Max. travel of cross slide 493mm
Travel of top slide 200mm
Main motor power 11kw
Rapid traverse motor power 1.1kw
Coolant pump motor power 0.09kW



CDS6250

Features

  • 3-jaw chuck
  • Steady rest
  • Center tools
  • Face plate
  • Drive plate
  • Toolpost guard
  • Chuck guard
  • Full splash guard
  • Oil gun
  • Foundation bolts
  • Tool brake

Brochure

Specifications

Specifications

Swing over bed                                                      500mm
Swing over cross slide  290mm
Swing over gap  760mm
Gap length  280mm
Dist. centers 750/1000/1500/2000/3000
Spindle bore 82/105
Taper of spindle bore  90/1:20
Spindle nose  D8
No. of Spindle speed  16
Spindle speed ranges 26-2000/26-1700rpm
Maximum spindle motor power  705kw(3/10HP)
Width over bedways  394 mm
Cross slide travel X axis  355mm
Travel of top side  150mm
Max. dimension of tool shank  25 x 25 mm
Range of Imperial Pitches  7/16-80 TPI
Range of Diametral Pitches  7/8-160DP
Range of Metric Pitches  0.35-80 mm
Range of Module Pitches  0.2-40 MOD
Tailstock quill diameter 75 mm
Tailstock quill taper  No. 5MT
Tailstock quill travel  150 mm
