Video Measuring

Video Measuring Machines are specifically designed for non-contact measurement and inspection of intricate features on small or large parts.  These systems are ideal for quality assurance, inspection labs, manufacturing, assembly and research facilities. A precision mechanical bearing X-Y-Z stage and column translates data accurately and repeatably to operating system software. Video measuring systems are a natural step up from measuring microscopes and optical comparators. These systems may be configured with measurement software or metrology specific DROs.

Starrett MV300 Video Measuring System

The Starrett MV 300 system is a general-purpose manually driven video based measurement system, ideal for quality assurance, inspection labs, manufacturing, assembly and research facilities.

A precision mechanical bearing X-Y-Z stage and column, combined with Heidenhain scales, translates data accurately and repeatedly to the user friendly Metlogix M3 software, which is all stored and viewed on neat and compact all-in-one touch screen PC.

Specifications

Specifications

X/Y/Z Measuring Range 300x150x125mm
X/Y Accuracy in µm E1=3.5+5L/1000
Z accuracy in µm E1=2.5+5L/1000
Control System / Software Metlogix M3
Zoom Optics 6.5:1
S Video Colour Camera  Supplied as standard
Surface Ring Illumination LED or Fi-O
Transmitted Illumination Supplied as on option
Coaxial Illumination Supplied as on option
Dark Field Quadrant Illumination .5x, 2.0X
Auxiliary Lenses (Optional) Supplied as an option
Workstation  Supplied as an option
Video Pixel Calibration Standards Supplied as an option
Calibration Standards Supplied as an option

Video

Video

AV300 CNC Vision System

The AV300 CNC vision system offers 12" x 6" x 5.5" travel, Z-axis measuring, your choice of powerful MetLogix or Quadra-Check software control systems, 6.5:1 (optional 12:1) zoom optics and several LED or fiber optic illumination options. These systems are general-purpose CNC video-based measurement systems. Throughput is maximized with either QC5000 or Metlogix M3 software controlling all aspects of Video Edge Detection (VED) and multiple channel Fiber Optic or LED illumination. Available with an all-in-one touchscreen PC with MetLogix M3 DXF/FOV/CNC software, or with a desktop PC with an external monitor and QC5000 software. The M3 software supports 2D geometrical constructs (lines, angles, circles), while the QC5000 software also supports 3D constructs (inclined planes, cones, spheres). Starrett automatic vision (AV) systems are ideal for quality assurance, parts inspection, and production runs. Flexible and powerful the AV series allows users to cost effectively achieve maximum throughput of their inspection process, allowing measured data to be effectively archived or networked to other devices. Also see our multi-sensor metrology systems, which can provide vision metrology operation with travel up to 50" x 36" x 8" (1270 x 915 x 200 mm).

Specifications

Specifications

X-Y-Z Travel: 300x150x135mm
Z Axis Measuring: Standard
X-Y Accuracy (µm): E2 = 1.9µm + 5L/1000
Z Accuracy (µm): E1 = 2.5 µm + 5L/1000
Scale Resolution: 0.1 µm
Multi-Sensor Compatible: Yes
Base: Cast Aluminum
Control System / Software: M3 or QC5300
Display: 21" Touchscreen PC or 24" Monitor
Zoom Optics - Standard: 6.5:1
Zoom Optics - Optional: 12:1
Digital Video Camera: 1 MP Color
Surface Ring Illumination: LED or FO
Transmitted Illumination: LED or FO
Coaxial Illumination: Optional LED or FO
Darkfiled Quadrant Illumination (Optional LED only): Optional LED
Brightfield Quadrant Illumination (Optional LED only): Optional LED
Auxiliary Lenses (Optional): 0.5X, 1.5X, 2.0X
Renishaw Touch Probe: Optional on QC5300 only
Renishaw Touch Probe Change Rack: Optional on QC5300 only
Workstation Base, Extension and Swing Arm: Optional
Part Fixturing: Optional
Video Pixel Calibration Standard: Optional
Calibration Standards: Optional



AVR300 CNC Vision System

The Starrett AVR Series CNC automatic vision metrology systems are ideal for repetitive measurements and automatic comparison to CAD files. They are available with dedicated 6.5:1 or 12:1 zoom optics or a quick-change bayonet lens mount which accepts a choice of six interchangeable telecentric lenses for micron-level resolution and optical distortion down to 0.001% for accurate field-of-view (FOV) measurements. The FOV can encompass an entire small part up to 2.00 x 1.50" or a feature of a larger part and be seamlessly integrated with stage motion to measure parts with a length up to 8" (AVR200) or 12" (AVR300). Systems are also touch probe compatible. AVR Series hardware features include a granite base for maximum stability, recirculating ball linear guides for smooth and precise stage motion, and full CNC control for high throughput. All electronics other than the PC are housed in the Z-column, ensuring an integrated system with minimal external wiring.

Specifications

Specifications

X-Y-Z Travel: 300 x 200 x 200mm
Z-Axis Measuring: Standard
CNC: Standard
X-Y Accuracy (µm): E2 = 1.9 µm + 5L/1000
Z Accuracy (µm): E1 = 2.5 µm + 5L/1000
Scale Resolution: 0.1 µm
Base: Granite
Control System / Software: M3
Display: 21" Touchscreen PC
Zoom Optics - Standard: 6.5:1
Zoom Optics - Optional: 12:1
Digital Video Camera: 1 MP Color Std. 2MP with Telecentric
Surface Ring Illumination: LED
Transmitted Illumination: LED
Coaxial Illumination: Optional LED
Darkfiled Quadrant Illumination (Optional LED only): Optional LED
Brightfield Quadrant Illumination (Optional LED only): Optional LED
Auxiliary Lenses (Optional): 0.5X, 1.5X, 2.0X
Telecentric Lenses (Required on FOV & HDV): .3X, .5X, .8X, 1.0X, 2.0X, 4.0X
Rotary Fixture: Optional
Workstation Base, Extension and Swing Arm: Optional
Part Fixturing: Optional
Video Pixel Calibration Standard: Optional
Calibration Standards: Optional
