WEDM - MITSUBISHI

Wire cut EDM (or WEDM) discharges the electrified current by means of a taut thin wire, which acts as the cathode and is guided alongside the desired cutting path, or kerf. A dielectric fluid submerges the wire and workpiece, filtering and directing the sparks. The thin wire allows precision cuts, with kerfs as wide as three inches and a positioning accuracy of +/- 0.0002”. This heightened precision allows for complex, three dimensional cuts, and produces highly accurate punches, dies, and stripper plates.

MV 1200S (Generally Ex Stock)

• Innovative automatic wire threading-Intelligent AT- Advanced technology for greatly improved productivity
• Improved machining accuracy -Opt Drive System- Next-generation drive system and refined power-supply control technology
• Improved productivity -Precise Finish Circuit- Wide range of technologies for ever-changing working environments
• Easy operation -Natural User Interface- User-friendly features ensure easy operation
• Energy savings, low running cost -Long Life System- Realizing low costs and environment-friendly operation
• ADVANCE PLUS control - Super Digital Control x ADVANCE PLUS control expand the capabilities of electrical-discharge machining



Specifications

Specifications

Maximum workpiece dimensions 810x700x215mm
Tolerable workpiece weight 500kg
Table dimensions (W x D) 640x450mm
Each axis stroke (X x Y x Z) 400x300x220mm
Outline dimensions (W x D x H)  2025x2760x2015mm
Machine body weight  2700kg
Work tank door     Manual vertical front door



Video

Video

MV 1200R

Introducing the MV1200-R Advance Plus. The new machine features the M700 series control with a 15-inch touchscreen for easier user interface. Mitsubishi is dedicated to constant innovation and strives to build only the highest quality machines. The MV series features new improvements in machine construction, auto-threading, internal machine communication, power supply technology and operating costs. The MV1200-R also includes a new, non-contact Cylindrical Drive System. The machine's improved features are sure to advance your EDM machining.



Specifications

Specifications

Machine Travels X x Y x Z  400x300x220mm
Maximum Workpiece Dimensions 810x700x215mm
Max. Submerged Workpiece Weight 500kg
Table Dimensions 640x540mm
Table Rapid Feed Speed     1300mm/min
Minimum Drive Unit/Resolution 0.000002/2µin (0.00005/50nm)
Wire Diameter Possible 0.1~0.3mm
Minimum Start Hole Diameter 0.5mm
Machine System Dimensions 2025x2702mm
Machine Installed Height 2015mm
Machine System Weight 2700kg



Video

Video

MV2400S

MV2400S

• Innovative automatic wire threading-Intelligent AT- Advanced technology for greatly improved productivity
• Improved machining accuracy -Opt Drive System- Next-generation drive system and refined power-supply control technology
• Improved productivity -Precise Finish Circuit- Wide range of technologies for ever-changing working environments
• Easy operation -Natural User Interface- User-friendly features ensure easy operation
• Energy savings, low running cost -Long Life System- Realizing low costs and environment-friendly operation



Specifications

Specifications

Machine Travels X x Y x Z  600x400x310mm
Maximum Workpiece Dimensions 1050x820x305mm
Max. Submerged Workpiece Weight 1500kg
Table Dimensions 840x560mm
Table Rapid Feed Speed     1300mm/min
Minimum Drive Unit/Resolution     0.000002/2µin (0.00005/50nm)
Wire Diameter Possible 0.1~0.3mm
Minimum Start Hole Diameter 0.5mm
Machine System Dimensions 2687x3030mm
Machine Installed Height 2150mm
Machine System Weight 3500kg
Fluid System Weight 350kg



Video

Video

MV2400R

The new innovative MV-R series features improvements in machine construction, auto-threading, internal machine communication, power supply technology and operating costs. For easier user interface, the MV2400-R Advance Plus M800 utilizes the new Mitsubishi M800 series control with a 19-inch cell phone like touchscreen. It also showcases Mitsubishi's continuous dedication to high precision through new innovations - including the highly reliable non-contact Cylindrical Drive System on the X, Y, U & V axis drives. The technology available with the MV2400-R M800 represents significant advancements in wire EDM technology.

Specifications

Specifications

Machine Travels                                               600 x 400 x 310mm
Maximum Workpiece Dimensions                    1050 x 820 x 305mm
Max. Submerged Workpiece Weight                1500kg
Table Dimensions                                             840 x 640mm
U/V Travels (from center)                                 ±75 x ±75mm
Taper Angle @ Thickness                                15 deg.@ 260mm
Table Rapid Feed Speed                                  1300mm/min






MV4800 Advance

MV4800 Advance is now capable of submerged cutting up to 20.0 inches deep with full support of the best auto-threading system on the market today. With an annealing length of over 27 inches, this system is capable of threading the maximum workpiece height both at the start point and through the gap if needed for a broken wire recovery. The MV4800 features the highly reliable non-contact cylindrical drive system and the M700 series control with a 15-inch touchscreen. With advancements in machine construction and power supply technology, the MV4800 is sure to revolutionize EDM machining and increase your shop's productivity.

Specifications

Specifications

Machine Travels X x Y x Z: 800 x 600 x 510mm
Maximum Workpiece Dimensions: 1350 x 1100 x 500mm
Max. Submerged Workpiece Weight: 3000kg
Table Dimensions: 1150 x 975mm
U/V Travels (from center): ±100 x ±100mm
Taper Angle @ Thickness: 15 deg.@ 365mm
Wide Angle Taper: 45 deg. @ 2.4" (No AT Possible)
Table Rapid Feed Speed: 1300m/min
Power Supply: V350-V
Minimum Drive Unit / Resolution: 0.0001/0.05µm
User Program Storage [Hard Disk Size]: 1 GB [80 GB]
Wire Diameter Possible: 0.15~0.3mm
Minimum Start Hole Diameter: 0.5mm
Max. Wire Spool size STD [optional]: 44kg, 20kg
Filters/Type: 2/Paper
Filter Tank Capacity: 1110L
Machine System Dimensions: 3300 x 3775mm
Machine Installed Height: 2815mm
Machine System Weight: 5488kg
Fluid System Weight: 450kg
Power Requirements: 200-230V
Compressed Air Requirements: 2.7 cu.ft./min. @ 71~100 psi

MX 600 ADVANCE TUBULAR

Features

  • Advanced manual control box
  • Oil specialized power supply (nPV power supply)
  • Super finish circuit (nFS circuit)
  • LAN/W • DNC
  • File server connection (FTP)
  • Angle Master (S/W)
  • Anti-virus protection
  • Sleep mode



Brochure

Specifications

Specifications

Travel (X/Y/Z) in mm     300 / 200 / 180
Travel (U/V) in mm     70 / 70
Taper angle (workpiece height) in °/mm    15 / 100
Max. workpiece dimensions (W x D x H) in mm     620 x 610 x 100
Max. workpiece weight in kg     300
Table dimensions (W x D) in mm     560 x 485
Table layout     Hardened 4-side table
Possible wire diameters in mm     0,03–0,20
Wire spool capacity in kg   10
Automatic wire threader     Yes
Overall dimensions (W x D x H) in mm     1970 x 2800x 2100
Machine weight in kg     3400
Mains voltage     3-phase 400 V/AC ± 10 %, 50/60 Hz, 20 kVA
Tank capacity in L 300
Temperature control     Dielectric cooling unit



Video

Video

FA30-S WEDM

Your requirements for a modern wire eroding system are highly varied and your customer´s demand will continue to rise. What does it mean for you? The FA-S Advance is the solution for your manufacturing process. You can realise compound tools, graphite electrodes, gear moulds, profiles, plastic moldings and single-part or serial production quickly and reliably with the FA-S Advance, which covers the complete application range. Even special demands from medical as well as aircraft and space industry are the domain of this machine series. Since we are Mitsubishi Electric, the world-wide leader in spark erosion, you can expect this from us. Our outstanding reliability and operational safety in spark erosion remains unparalleled.

Designed for workpieces of up to 4 tonnes. There is little else we need to say regarding the rigidity and stability. Furthermore, there is the high-resolution digital controlled direct drive system
(0.05 µm resolution) and a generously dimensioned ballscrew, including 10 years warranty on positioning accuracy. Both features guarantee continuous precision over an extremely long working life. The table for workpiece clamping, with its vertical slidingdoor has been ergonomically designed with the operator in mind. Ease of maintenance is a core design feature demonstrated by the patented self-cleaning system of the working tank seal plate as well as the fully automatic central lubrication system. These are only a few examples of the intelligent design applied to Mitsubishi´s latest FA-Series machine. Needless to say
quality is also important to us, and all FA machines are checked by laser measurement, roundness tests and extensive controls among other things. Because precision needs perfection.

The FA-S Advance generates outstanding, precise results - not only under laboratory conditions, but also in dayto-day activities. After all, this is ultimately the decisive factor for you. Astonish your customers with exceptional results and reasonable prices made possible by the most progressive technology and low operating costs. Surface finishes of less than 0.15 µm Ra, cutting speeds up to 500 mm2/min, and parallelism from 5 µm on the diameter at a cutting height of 200 mm are achievable. The FA-S Advance continues to work reliably even in the most difficult flushing conditions such as conic angles up to 45°, offset or intermittent workpieces, thereby delivering precise and lasting results that are reproducible.

The Automatic Threading System (AT) threads the wire in only 10 seconds and combined with the standard wire chopper you will achieve ultimate speed, safety and comfort. Overall machine operation is made easy with all the operating and maintenance elements easily reached. And if you are off site? You can still have access to the machine functions via Telecontrol. This function allows you to control and monitor your eroding system through a datalink in real time. Another monitoring option is our intelligent Telecontact system. It allows you to transfer machine messages via SMS to a mobile phone. And for the highest level of help and support you can rely on remote diagnosis and online help through our Teleservice. With this system our customer service team can support you for all problems by means of direct online access to the machine.

Specifications

Specifications


Model FA10, FA20, FA30
Machine dimensions 1575 x 1667 x 1930mm, 2013 x 2632 x 2100mm, 2560 x 2650 x 2150mm
Machine unit weight 2000kg, 3500kg, 4600kg
Max. Workpiece Weight 500kg, 1500kg, 3000kg
Table Dimension (WxD) 590 x 514mm, 780 x 630mm, 1100 x 875mm
Table height (from floor) 900mm
Table rapid-feed speed 1300mm/min
Travel path (U/V) ±32mm, ±32mm, ±75mm
Travel path (X/Y/Z): 350 x 250 x 220mm, 500 x 350 x 300mm, 750 x 500 x 350mm
Z-axis device Standard equiment (=5.axis)
Taper 15°/100 mm 15°/100 mm
Max. taper angle 15° (bei Werkstückhöhe 260mm)
Taper machining device Standard equiment (=3. And 4.axis)
Useable Wire diameter 0,2 ~ 0,3

FA40-S WEDM

Your requirements for a modern wire eroding system are highly varied and your customer´s demand will continue to rise. What does it mean for you? The FA-S Advance is the solution for your manufacturing process. You can realise compound tools, graphite electrodes, gear moulds, profiles, plastic moldings and single-part or serial production quickly and reliably with the FA-S Advance, which covers the complete application range. Even special demands from medical as well as aircraft and space industry are the domain of this machine series. Since we are Mitsubishi Electric, the world-wide leader in spark erosion, you can expect this from us. Our outstanding reliability and operational safety in spark erosion remains unparalleled.

Designed for workpieces of up to 4 tonnes. There is little else we need to say regarding the rigidity and stability. Furthermore, there is the high-resolution digital controlled direct drive system
(0.05 µm resolution) and a generously dimensioned ballscrew, including 10 years warranty on positioning accuracy. Both features guarantee continuous precision over an extremely long working life. The table for workpiece clamping, with its vertical slidingdoor has been ergonomically designed with the operator in mind. Ease of maintenance is a core design feature demonstrated by the patented self-cleaning system of the working tank seal plate as well as the fully automatic central lubrication system. These are only a few examples of the intelligent design applied to Mitsubishi´s latest FA-Series machine. Needless to say
quality is also important to us, and all FA machines are checked by laser measurement, roundness tests and extensive controls among other things. Because precision needs perfection.

The FA-S Advance generates outstanding, precise results - not only under laboratory conditions, but also in dayto-day activities. After all, this is ultimately the decisive factor for you. Astonish your customers with exceptional results and reasonable prices made possible by the most progressive technology and low operating costs. Surface finishes of less than 0.15 µm Ra, cutting speeds up to 500 mm2/min, and parallelism from 5 µm on the diameter at a cutting height of 200 mm are achievable. The FA-S Advance continues to work reliably even in the most difficult flushing conditions such as conic angles up to 45°, offset or intermittent workpieces, thereby delivering precise and lasting results that are reproducible.

The Automatic Threading System (AT) threads the wire in only 10 seconds and combined with the standard wire chopper you will achieve ultimate speed, safety and comfort. Overall machine operation is made easy with all the operating and maintenance elements easily reached. And if you are off site? You can still have access to the machine functions via Telecontrol. This function allows you to control and monitor your eroding system through a datalink in real time. Another monitoring option is our intelligent Telecontact system. It allows you to transfer machine messages via SMS to a mobile phone. And for the highest level of help and support you can rely on remote diagnosis and online help through our Teleservice. With this system our customer service team can support you for all problems by means of direct online access to the machine.

Specifications

Specifications

Model FA10, FA20, FA30
Machine dimensions 1575 x 1667 x 1930mm, 2013 x 2632 x 2100mm, 2560 x 2650 x 2150mm
Machine unit weight 2000kg, 3500kg, 4600kg
Max. Workpiece Weight 500kg, 1500kg, 3000kg
Table Dimension (WxD) 590 x 514mm, 780 x 630mm, 1100 x 875mm
Table height (from floor) 900mm
Table rapid-feed speed 1300mm/min
Travel path (U/V) ±32mm, ±32mm, ±75mm
Travel path (X/Y/Z): 350 x 250 x 220mm, 500 x 350 x 300mm, 750 x 500 x 350mm
Z-axis device Standard equiment (=5.axis)
Taper 15°/100 mm 15°/100 mm
Max. taper angle 15° (bei Werkstückhöhe 260mm)
Taper machining device Standard equiment (=3. And 4.axis)
Useable Wire diameter 0,2 ~ 0,3
