CNC Controls

CNC or Computer Numerical Controls are the operating system or brain of a CNC system. A controller completes the all important link between a computer system and the mechanical components of a CNC machine. The controller's primary task is to receive conditioned signals from a computer or indexer and interpret those signals into mechanical motion through motor output. There are several components that make up a controller and each component works in unison to produce the desired motor movement.

808D (Entry Level Control)

Thanks to its panel-based CNC design requiring only few interfaces and an operator panel with degree of protection IP65, the SINUMERIK 808D/808D ADVANCED is perfectly prepared for the use in harsh environments. With its small dimensions, it can be used on compact machines. At the same time, the SINUMERIK 808D/808D ADVANCED allows convenient operation with short-stroke keys and the well-known SINUMERIK softkeys.

Typical fields of application - Perfectly preconfigured for:

  • Basic standard machines with up to 4 axes/spindle in one machining channel
  • Inclined bed and flatbed CNC machines
  • Flatbed manual controlled semi-CNC lathes (Manual Machine plus)

Benefits

  • Simple and intuitive operator interface - thanks to dialog-based user support with SINUMERIK Operate BASIC
  • Wide range of technology cycles - for turning and drilling with graphical input screens SINUMERIK programGUIDE BASIC
  • High performance and precision - thanks to modern CNC functions
  • Connecting Machine Control Panel using a simple plug & play USB port - equipped with same ergonomically designed override rotary switches as in high-end CNCs



Brochure

Video

Video

828D Basic ( Mid Range Control )

Turning and milling operations on standardized machines as well as functions for the easy automation of grinding machines – this where SINUMERIK 828D ADVANCED, SINUMERIK 828D and SINUMERIK 828D BASIC, with their unique CNC performance, set standards regarding productivity.

Due to the technology-specific system software, the field of application of the SINUMERIK 828 controls ranges from vertical and basic horizontal machining centers – including, of course, mold making applications – to flat and rotary grinding machines through to dual-channel turning centers with counterspindle, driven tools and Y axis.

Features
- Panel-based compact CNC
- Technologies: Turning, milling, grinding functions
- Up to 10 axes/spindles + 2 auxiliary axes
- Up to 2 machining channels
- 8.4" / 10.4" color display
- S7-200 PLC

Benefits

Rugged
An operator panel front made of magnesium die cast, the panel-based CNC design with well-conceived interfaces, as well as the high degree of protection IP 65 make the SINUMERIK 828 controls a reliable partner even in harsh environments.

Maintenance-free
Thanks to the configuration without fan or hard disk and the NV-RAM storage technology without back-up battery, the SINUMERIK 828 controls are completely maintenance free.

User-friendly
Thanks to a fully-fledged QWERTY CNC keyboard with short stroke keys and a high-resolution 8.4"/10.4" TFT color display, the SINUMERIK 828 controls can be easily operated. The USB, CF card and RJ45 interfaces on the operator panel front allow to quickly transfer the CNC data in an uncomplicated manner.



Brochure

Brochure

PDF icon 828D Basic.pdf

Video

Video

828D

The SINUMERIK 828D sets new standards of ruggedness and ease of operation in the compact CNC class. Even in the compact frame size, its state-of-the-art technology ensures the highest possible levels of precision and productivity. The performance of the SINUMERIK 828D is in a class of its own.

Coupled with the SINAMICS drive and motor system, the integrated SINUMERIK 828D really gets your machine tool going. Provides unparalleled potential for turning and milling workpieces more productively. With ShopMill/ShopTurn sequence programming, the SINUMERIK 828D boasts the most straight forward CNC program editor in the world.



Brochure

Brochure

PDF icon 828D.pdf

Video

Video

840D sl (High End 5-axis Simultaneous )

SINUMERIK 840D sl is with good reason considered as the measure in the CNC premium class. Utmost CNC performance as well as unreached flexibility and openness are the basis for nearly every machine concept.

Typical applications

High-performance milling and turning is one of the strengths of the SINUMERIK 840D sl. Further, the SINUMERIK 840D sl opens up a nearly inexhaustible technology range: From grinding and laser machining to gearwheel machining through to multitasking machining. With its superior system flexibility, the SINUMERIK 840D sl is the CNC of choice when opening up completely new technology fields.

SINUMERIK 840D sl - Overview of the technology
- Drive-based modular CNC
- Multi-technology CNC
- Up to 93 axes / spindles
- Up to 30 machining channels
- Modular panel concept
- Up to 19“ color display
- SIMATIC S7-300 PLC

Benefits

Modular and scalable
In addition to a scalable NCU performance, the SINUMERIK 840D sl also provides excellent modularity of the operator components. With a flexible M:N operator concept – e.g. the combination of arbitrary operating fields with the NCU – the SINUMERIK 840D sl can be ideally adjusted to the operator philosophy applied by state-of-the-art premium machine concepts.

Benchmark in Open Architecture
The open system architecture of the SINUMERIK 840D sl is unique. For example, the CNC can be optimally adjusted to the machine technology and shows a high degree of freedom in production automation.

Communicative at all levels
With PROFINET, the SINUMERIK 840D sl is perfectly integrated in the Siemens TIA environment. Totally Integrated Automation stands for unrivaled total integration – from the field level to the production level through to the manufacturing execution level.



Brochure

Brochure

PDF icon 840Dsl.pdf

Oi-MD

Oi-MD Features

  • Digital Servo Function
  • 1 Controlled Path
  • Simultaneously controlled axes: Up to maximum of 4; 3 if Contouring Spindle Configured
  • PMC Axis Control
  • Simple synchronous control
  • Tandem control
  • Serial Encoder Interface
  • Axis Name: Selected from X,Y,Z and U,V,W,A,B,C
  • Spindle: Up to two Spindles
  • Least input increment: 0.001mm, 0.001deg, 0.0001inch
  • Increment system: 1/10 0.0001mm, 0.0001deg, 0.00001inch
  • Flexible feed gear: Optional DMR
  • Fine Acc & Dec control
  • Inch/metric conversion
  • Interlock: All axes/each axis/each direction/block start/cutting block start
  • Machine lock: All axes/each axis
  • Emergency stop
  • Overtravel
  • Stored stroke check 1
  • Stored stroke check 2
  • Stroke limit external setting
  • Mirror image Each axis
  • Follow-up
  • Servo off
  • Backlash compensation
  • Backlash compensation for each rapid traverse and cutting feed
  • Stored pitch error compensation
  • Position switch
  • Unexpected disturbance torque detection function



Oi-MB

Oi-MB Features

  • Digital Servo Function
  • 1 Controlled Path
  • Simultaneously controlled axes: Up to maximum of 4; 3 if Contouring Spindle Configured
  • PMC Axis Control
  • Simple synchronous control
  • Serial Encoder Interface
  • Axis Name: Selected from X,Y,Z and U,V,W,A,B,C
  • Spindle: Up to two Spindles
  • Least input increment: 0.001mm, 0.001deg, 0.0001inch
  • Increment system: 1/10 0.0001mm, 0.0001deg, 0.00001inch
  • Flexible feed gear: Optional DMR
  • Fine Acc & Dec control
  • Inch/metric conversion
  • Interlock: All axes/each axis/each direction/block start/cutting block start
  • Machine lock: All axes/each axis
  • Emergency stop
  • Overtravel
  • Stored stroke check 1
  • Stored stroke check 2
  • Stroke limit external setting
  • Mirror image: Each axis
  • Follow-up
  • Servo off
  • Backlash compensation
  • Backlash compensation for each rapid traverse and cutting feed
  • Stored pitch error compensation
  • Position switch
  • Unexpected disturbance torque detection function
M700 Series

M700 Series

Cutting-edge, full-fledged nano-control

  • Nano-interpolation for high-quality machining results
  • Full-fledged nano control for optimum performance
  • High-speed, high-precision die/mold cutting
  • SSS Control for stable machining quality

Increased speed, precision and quality

  • Optimum Machine Response (OMR) control
  • OMR-Feed Forward (FF) control for accurate cutting according to machining commands
  • High-gain Control II improves basic servo system performance
  • M-DDC function reduces synchronized tapping time and increases precision

A wealth of functions to Support intermixed machining needs

  • Synchronization Control (milling)
  • 5-axis machining function (milling)
  • Systems/start point synchronization (turning)
  • Mixed machining command (turning)
  • Milling interpolation (turning)

Enhanced operability reduces set-up time

  • Display of essential information for easy understanding
  • Pop-up Screens for added ease of use
  • Program input error warning function
  • Easy-to-use Menu List display and Help function

Screens developed for optimum ease of use

  • Communication terminals support easy use and high performance
  • Standard PCMCIA slot
  • Advanced-functions model equipped with WindowsXPe
  • USB port
  • Superb environmental performance
  • 17 languages supported



M800

In developing the M800/M80 Series, Mitsubishi went back to the drawing board and completely reexamined their cutting-edge control

technologies. The result is a breakthrough in the control of high-speed, high-precision machining. The M800 has a CNC-dedicated CPU

which not only results in phenomenal processing speed, but also reduces the number of required parts, leading to fewer possibilities of

failure and increasing product quality.



Advanced Design

- Display and keyboard design have been renewed.
- The advanced construction and sophisticated flat profile take machine design to the next level.
- The display incorporates a touchscreen as standard specifications,
- providing intuitive smartphone-like operation (10.4-type and wider displays).



Smartphone-like intuitive touch operation

The display features a capacitive touchscreen that is commonly used in smartphones and tablets, allowing for intuitive and easy

operation. With a simple flick of the finger, for instance, you can monitor the desired part of program, or view and select a menu

key on thenext page without the need for tedious key operation.



M800W - Premium CNC with Windows-based display provides expandability and flexibility

M800S - High-grade CNC well suited to high-speed high-accuracy machining and multi-axis multi-part system control

M80 - Standard CNC provides high productivity and easy operability



Specifications

Specifications

GSM frequencies 900   1800
Dimensions (W x H x D) 89.00 x 45.00 x 22.00mm
Weight 94.00 g
Main display Color / TFT
                                                 256k colors
                                                 128 x 160 px (0.00")

Talk time (max.)                     2G: 150 min. (2.5 h)
Stand-by (max.)   2G: 250 h (10.4 days)
Standard battery Li-Ion 680 mAh
Phonebook memory 500 places
Internal memory 1.5 MB
SAR (10g)                            0,7 W/kg
Syntech 6MA

Syntech 6MA

  • Milling CNC Controller from Taiwan
  • Ethernet Fast Program Transmission
  • Alarm history up to 200 Alarms
  • Production history of last 100 programs
  • Block processing speed - more than 300 blocks
  • Online LADDER
  • Windows based CE Software
  • Service Interval Reminder and Machine lock feature
  • Closed Loop SYNTEC CNC Controller
  • Can be interfaced with any Pulse Input based Servo Drive
  • HSHP - High Speed High Precision Parameters
  • Many more features to Explore in SYNTEC CNC Controller



Arumatic - Exclusive to Kitamura Machines

Arumatic - Exclusive to Kitamura Machines

The user interface is the Windows XP operating system, offering the user the ability to simultaneously execute programs while engaging any compatible Windows based software, to include any CAD/CAM systems. A 3-year control components warranty comes standard with purchase.

The Arumatik-Mi control offers the user more practical communication and visible use. Operation processes are divided into three steps, ‘Monitor’, ‘Set-Up’ and ‘Edit’, and necessary information is aggregated into the three screens. These screens can be displayed by just a single touch of a button on the keyboard or touch screen. Customizable tabs allow the user to select necessary operation from the operation menu, and pop-up screens allow the user to access desired information while the original screen remains displayed.

Standard with a 19” LCD and dual keyboard layout (Kitamura conventional style control coupled with standard keyboard design) the Arumatik-Mi control offers comfortable and advanced operation for a variety of machining applications along with the ability to transfer existing Fanuc programs. The operation panel swings out 90º and comes equipped with a standard fixed remote pulse generator, making set-up for the operator easier.

Video

Video
