Gear Hobbing

H100

The H 80-200 series is the latest version of our hobbing machine line for small automotive applications, specially engineered for automotive applications. These machines have been designed for dry cutting applications in particular, although using oil or emulsion is not a problem. Chips are conveyed cleanly from the work area by means of a chute, which is steep and smooth in design to prevent any build up. The hob head is housed within the tool column, which is tightly fastened to the sturdy machine bed. The tailstock is located on the tool column above the hob head, leaving the work area remarkably free for workpiece loading and unloading operations.

To cater for your line automation needs, the machine is available with a standard, direct-driven double gripper loader. Placing a machine in close proximity to your workpiece conveyor belt, in fact, requires no further automation other than that provided by the completely integrated solution. All peripheral units are easily accessible and maintenance-friendly (including pneumatics, hydraulics, electrics and chip disposal).

The machines can either be used as high-speed mass production tools or as power houses to obtain high-torque cutting performances, thanks to the different drive variants available. Moreover, the direct drive technology incorporated in this series makes your machine a safe investment over time, since any future tool developments can be fully exploited.

Fast and easy operator guidance throughout the whole process is guaranteed by the latest Siemens Sinumerik 840 D dialogue software, and the ability to make flexible tooth flank and crowned root corrections, ensures optimum roughing results for pre-shave, pre-grind or pre-hone applications.

  • Dry cutting
  • Chute conveys chips cleanly
  • Siemens Sinumerik 840 D control
  • Fast and easy operator guidance
  • Latest dialogue software
  • Flexible tooth flank capability

Specifications

Specifications

Maximum Module mm 4
Maximum workpiece dia. mm 100
Maximum Axial Cutting Length mm 100-450
Maximum Hob Diameter mm 90
Maximum Hob Length (bore type) mm 190
Maximum Hob Length (shank type) mm 285
Maximum Hob Swivel deg +/- 45°
Maximum Hob Shift mm 325
Hob Speed Range (RPM) 1/min 250-3500
Workspindle Maximum Speed (RPM) 1/min 1000
Hob Drive Power kW 15
Total Connected Load kVA 35
Width (Approximate) mm 2600
Height (Approximate) mm 2850
Length (Approximate) mm 2300
Weight (Approximate Net) kg 8500

H160

The H100 is used in small and large batch production in automotive and general engineering industries. Rigid and thermally stable bed provides damping of vibrations during processing. Range of operations can be widened due to integration of technologies into the machine.

Features

  • Processing of gears with max. diameter 160 mm and module 4.0
  • Compact machine
  • Closed frame construction
  • High clamping force for shafts
  • Direct drive of the milling head and table
  • Wet (with coolant) and dry cutting
  • Quick chip disposal system excludes thermal deformation of the machine construction
  • High-speed integrated loader
  • Synchronous loading and clamping
  • CNC Siemens 840 D SL
  • Safety Integrated and HMI-Pro
  • Easy maintenance due to access to the machine from 3 sides
  • Integrated workpiece storage (option)
Column with quill and rotary axis
  • Radial movement at X -axis is performed using a quill principle
  • Milling head is integrated into the main column providing construction rigidness and, as a result, enhancing of processing accuracy
Working area for dry cutting
  • Fully enclosed working area and bed covered with stainless steel sheets provide thermal stability of the machine construction
  • Inclined surfaces of the working area provide quick and full disposal of hot chip
  • Nozzles supplying compressed air to the working area guarantee quick and full disposal of the smallest chip particles
Tailstock
  • Closed frame construction with a cross-beam provides optimal placement of tailstock components
  • Ideally suited for processing of gears and shafts
  • Leverless control of clamping force
  • SK 30 interface of workpiece clamping elements
High efficiency
  • Mounting of two hobs in one clamping unit for simultaneous processing of several types of gears
  • Highly efficient milling of parts with large modules and maximal material removal
Integrated feed units
  • Feed units are integrated into the machine hull for space saving
  • Large doors with viewing windows allow easy controlling of status of units and their maintenance
  • Valves and electrical components are marked and placed in a convenient order

Specifications

Specifications

Max. workpiece diameter mm 160
Max. module mm 4
Radial movement (Х) mm 45-135
Max. radial feed speed mm/min 10000
Tangential movement (Y) mm 200
Max. tangential feed speed mm/min 7500
Axial movement (Z) mm 100-450
Max. axial feed speed mm/min 10000
Milling spindle rotary speed rpm 250-3500
Milling spindle drive power kW 15
Milling spindle nominal torque Nm 190
Milling head swivel angle grad ±45
Tool clamping arbour fixture taper   ?22, 27, 32 / SK25
Max. mill diameter mm 90
Max. mill length mm 285
Max. table rotary speed rpm 10-1000
Table diameter mm 132
Table hole diameter mm 80 Н7
Total connected load kW 35
CNC system   Siemens 840 D Solutionline
Quantity of controlled CNC axes   6
Weight Kg 6500-8000
Overall dimensions (L х W х H) mm 2300x2600x2850

H200

The H 80/160/200 series is the second platform of our smallest hobbing machine line for automotive applications. These machines have been designed for dry cutting applications in particular, though using oil or emulsion is no problem. Chips are conveyed cleanly from the work area by means of a chute, which is steep and smooth in design to prevent any build up. The hob head is housed within the tool column, which is tightly fastened to the sturdy machine bed. The tailstock is located on the tool column above the hob head, leaving the work area remarkably free for workpiece loading and unloading operations. To cater for your line automation needs, the machine is available with a standard, direct-driven double gripper loader. Placing a machine in close proximity to your workpiece conveyor belt, in fact, requires no further automation other than that provided by the completely integrated solution. All peripheral units are easily accessible and maintenance-friendly (including pneumatics, hydraulics, electrics and chip disposal).

Moreover, the direct drive technology incorporated in this series makes your machine a safe investment over time, since any future tool developments can be fully exploited.

Fast and easy operator guidance throughout the whole process is guaranteed by our latest dialogue software on the Siemens Sinumerik 840 D control with the possibility to make flexible tooth flank.

Specifications

Specifications

Max. workpiece diameter mm 200
Max. module mm 4
Radial movement (Х) mm 60-150
Max. radial feed speed mm/min 10000
Tangential movement (Y) mm 200
Max. tangential feed speed mm/min 7500
Axial movement (Z) mm 100-450
Max. axial feed speed mm/min 10000
Milling spindle rotary speed rpm 250-3500
Milling spindle drive power kW 15
Milling spindle nominal torque Nm 190
Milling head swivel angle grad ±45
Tool clamping arbour fixture taper   ?22, 27, 32 / SK25
Max. mill diameter mm 90
Max. mill length mm 285
Max. table rotary speed rpm 10-1000
Table diameter mm 132
Table hole diameter mm 80 Н7
Total connected load kW 35
CNC system   Siemens 840 D Solutionline
Quantity of controlled CNC axes   6
Weight Kg 6500-8000
Overall dimensions (L х W х H) mm 2300x2600x2850

H400

Features

  • Processing of gears with max. diameter 400 mm and module 8.0
  • Compact machine
  • Closed frame construction
  • High clamping force for shafts
  • Direct drive of the milling head and table
  • Wet (with coolant) and dry cutting
  • Quick chip disposal system excludes thermal deformation of the machine construction
  • High-speed integrated loader
  • Synchronous loading and clamping
  • CNC Siemens 840 D SL
  • Safety Integrated and HMI-Pro
  • Easy maintenance due to access to the machine from 3 sides
  • Integrated workpiece storage (option)
Column with quill and rotary axis
  • Radial movement at X -axis is performed using a quill principle
  • Milling head is integrated into the main column providing construction rigidness and, as a result, enhancing of processing accuracy.
Working area for dry cutting
  • Fully enclosed working area and bed covered with stainless steel sheets provide thermal stability of the machine construction
  • Inclined surfaces of the working area provide quick and full disposal of hot chip
  • Nozzles supplying compressed air to the working area guarantee quick and full disposal of the smallest chip particles
Tailstock
  • Closed frame construction with a cross-beam provides optimal placement of tailstock components
  • Ideally suited for processing of gears and shafts
  • Leverless control of clamping force
  • SK 30 interface of workpiece clamping elements
High efficiency
  • Mounting of two hobs in one clamping unit for simultaneous processing of several types of gears
  • Highly efficient milling of parts with large modules and maximal material removal
Integrated feed units
  • Feed units are integrated into the machine hull for space saving
  • Large doors with viewing windows allow easy controlling of status of units and their maintenance
  • Valves and electrical components are marked and placed in a convenient order

Specifications

Specifications

Max. workpiece diameter mm 400
Max. module mm 8
Radial movement (Х) mm 60-285
Max. radial feed speed mm/min 10000
Tangential movement (Y) mm 240
Max. tangential feed speed mm/min 7000
Axial movement (Z) mm 200-600(200-800)
Max. axial feed speed mm/min 7000
Milling spindle rotary speed rpm 225-1800(300-3000)
Milling spindle drive power kW 14(31)
Milling spindle nominal torque Nm 550(190)
Milling head swivel angle grad ±45
Tool clamping arbour fixture taper   ? 32/SK25
Max. mill diameter mm 175(130)
Max. mill length mm
Max. table rotary speed rpm 1-400
Table diameter mm 330
Table hole diameter mm 100 H7
Total connected load kW 40
CNC system   Siemens 840 D Solutionline
Quantity of controlled CNC axes   6
Weight Kg 9500-11000
Overall dimensions (L х W х H) mm 4000x2420x2750(3050)

H600

Features

Powerhouse for gears, shafts and screw-type workpieces.

The H 600/800 is a very stabile and rigid machine for the most demanding cutting taks. The machine employs all hobbing techniques (axial, radial/axial, tangential, diagonal) of spur and helical gearings using one or multiple cut technology with climb or conventional feed exploiting the different tool solutions available on the market.

The H 600/800 series is equipped with an exceptionally strong tool spindle drive and a very stabile and stiff tool head to live up to all gear cutting tasks. Depending on the application we deliver the series with special PowerCutting options.

The H 600/800 series can be automated with a standard ring loader for heavy workpieces. The gripper stroke is operated independently. The loader positions are freely selectable (cam-free) and can be saved in the Modul HMI / Operator Dialogue program for each specific workpiece.

Highlights

- Very stable and rigid structure

- Wet and dry cutting

- High performance hob head with 1000 Nm

- Up to 210 mm in hob diameter

- Direct drive work table with table plate options

- Standard and special workpiece support solutions

- Ring loader for heavy workpieces

- Compact layout with integrated auxiliary units

PowerCutting™

For workpieces with larger modules and tooth depths the H 600/800 is also available in a PowerCutting™ Version featuring an extra high-torque hob spindle with an enlarged swivel angle range. With the PowerCutting™ head the performance of inserted blade tools can be exploited to the maximum. Workpieces can be hobbed or milled depending on lot sizes and tool cost considerations. Additionally you can choose an extended counter column to cut longer and often slimer shapes like rotors or long shafts.

Especially when cutting larger modules, extreme tooth depths, high helix angles, though and ductile materials or very long or heavy workpieces the PowerCutting™ hob head and the special machine options become a very useful choice.

Highlights PowerCutting™

- PowerCutting™ Head with 1,500 Nm

- Larger hob diameters up to 300 mm

- Enlarged swivel angle for high helix angles

- Special worktable design

- Extended counter column for longer workpieces

- Workpiece support solutions for longer parts
