Horizontal Machining Centres

A Machining Center with its spindle in a horizontal position. The Horizontal Machining Centers' design is favoured for uninterrupted production work. One reason for this is that the horizontal orientation encourages chips to fall away, so they don't have to be cleared from the table. Most Horizontal machining centers come standard with a auto pallet changer for loading and unloading while the machine is cutting.

Mycenter-HX250G

Mycenter-HX250G

  • Ideal for simultaneous 4-axis machining of small, detailed, highly accurate parts
  • Amazingly small footprint saves on valuable floor space
  • Positioning Accuracy: ±0.000078” Full Stroke, Repeatability: ±0.000039”
  • World's fastest rapid feed rates at 2,362ipm
  • Rigid Meehanite cast iron construction
  • High power, high-speed processing Arumatik-Mi CNC
  • Powerful 15,000rpm, dual contact spindle - Now Available, 30,000rpm HSK-E40 spindle!

Mycenter - HX300G

  • Field expandable 2-station APC with high-speed 4th Axis rotary table and rotary scale. DD Motor driven with rapids 54,000deg/min
  • Ultra-high- speed rapid/cutting feeds,60m/min
  • Ultra-high-speed tool change, T-T 1.3 seconds
  • High-performance THK double roller linear guideways system
  • Powerful 15,000min, 30HP Direct Drive Dual Contact Spindle 20,000min, HSK spindle is an available option
  • Ballscrew cooling and fine resolution linear scale feedback in X,Y,Z axes
Mycenter-HX400G

Mycenter-HX400G

  • Linear scale feedback system – fine pitch, high resolution ballscrews
  • Positioning Accuracy: ±0.000078”/full stroke, Repeatability: ±0.000039”
  • Expandable, 2-station rotating pallet system
  • Full 4th axis rotary table with high resolution rotary scale for 360ᴼ cutting capability
  • Highest grade Meehanite cast iron construction with world's fastest rapid feed rates of 2,362ipm with solid box ways
  • High-speed, 15,000 direct driven, dual contact spindle. Optional 20,000rpm now available!
  • High precision contour control for complex contouring & mold applications
Mycenter-HX500G

Mycenter-HX500G

  • #40 Taper, 20,000rpm and #50 Taper, 12,000rpm spindle configurations. HSK spindle available as an option
  • Positioning Accuracy: ±0.000078”/full stroke, Repeatability: ±0.000039”
  • Solid box way construction, linear scales on all axes and twin ballscrew design in the X & Y axes
  • Full 4th axis rotary table for 360ᴼ cutting capability
  • World's fastest rapid feed rates of 2,362ipm on solid box ways
  • Standard 2-station APC offers the ability to add pallets and pallet pool systems in the field
  • Beats the competition in work envelope size and stroke!
Mycenter-HX800G

Mycenter-HX800G

  • #40 Taper, 20,000rpm and #50 Taper, 12,000rpm spindle configurations. HSK spindle available as an option
  • Positioning Accuracy: ±0.000078”/full stroke, Repeatability: ±0.000039”
  • Solid box way construction, linear scales on all axes and twin ballscrew design in the X & Y axes
  • Full 4th axis rotary table for 360ᴼ cutting capability
  • World's fastest rapid feed rates of 2,362ipm on solid box ways
  • Standard 2-station APC offers the ability to add pallets and pallet pool systems in the field
  • Beats the competition in work envelope size and stroke!
Mycenter-HX1000i

Mycenter-HX1000i

  • Solid box way design combined with the rigidity of high grade meehanite casting
  • Positioning accuracy: ±0.000078”/full stroke, Repeatability: ±0.000039”
  • Linear scale feedback on X, Y, Z axes
  • 1ᴼ indexer is positively positioned within ±1 arc/sec by a powerfully rigid curvic coupling
  • Maximum workpiece size 80.71” dia x 61.02” height. Table load capacity of 6,600Lbs +
  • Patented twin ballscrew/twin servo motor driven axis drive system
  • Flexibility with the ability to add a 5th axis in the field
