CNC Flat Bed Turning Center
CKE 6150Z x 2000
| Max. Swing over bed | 400 mm |
| Width of bed | 300 mm |
| Max. Length of work piece | 2000 mm |
| Max. Swing over slide | 200 mm |
| X travel | 225 mm |
| Z travel | 680mm |
| Spindle nose | D6 |
| Chuck size | 200 mm |
| Taper of spindle bore | M6 |
| Spindle bore | 52 mm |
| Steps of spindle speed | 2-step actuator |
| Frequency conversion motor power | 5.5 kW |
| Rapid traverse X/Z | 4/5m/min |
| Repeatability of tool post | 0.008 mm |
| Horizontal 6-position Tool post changing time | 3 |
| Diameter of tailstock quill | 63mm |
| Travel of tailstock quill | 130mm |
| Taper of tailstock quill | M4 |
| Net weigh | 1800Kg |
| Overall dimensions | 2300 x1480 x1520mm |
Features
- All main components, bed, headstock, saddle, plinth, etc., are high quality solid castings.
- Low friction Turcite-B coating on mating surfaces between saddle and guideways.
- Precision ballscrews and highly rigid precision bearings ensure accurate positioning and heavy cutting capability.
- Centralized oil system provides forced automatic lubrication onto ballscrews and all mating surfaces.
- Operator adjustable control panel enables convenient tool setting.
- Optional pneumatic or hydraulic chuck and tailstock are available.
