Portable Measuring - Arms

WD Hearn offers a range of Portable Measuring systems including the Nikon MMDx scanning head, MCAx Articualated measuring arm, and K-series Optical CMM. In basic terms these are accurate measuring systems that are used and manouvered by hand, and are easily transported by a single operator.

McAX Arm range

The MCAx Manual Coordinate measuring Arm is a precise, reliable and easy-to-use portable 7-axis measuring arm. It is the perfect partner for the ModelMaker MMDx/MMCx digital handheld laser scanners and Focus Handheld scanning and inspection software. This total solution’s accuracy, capability and portability make it feel perfectly at home in the metrology lab, on the shop floor and in-the-field.

The MCAx arm can be equipped with a wide range of probing systems for laser scanning, touch-trigger measurements and continuous scanning. Its flexibility makes this measurement arm the perfect solution for the widest range of measurement tasks. The new 7-axis MCAx range of articulated arms is available with a measurement volume ranging from 2.0 and 4.5 meter diameter.

Key benefits:

  • High accuracy and fast data throughput saves time and money
  • Optimized for hard-to-scan surfaces
  • Designed for use under all shop floor or field conditions
  • Extreme temperature stability and zero warm-up time
  • Quick and easy plug-and-play setup
  • Short learning curve
  • On-board calibration storage
  • Scanner compatible with all major brands of portable localizers and point cloud software
  • No external controller
  • Automatic probe recognition
  • Enhanced ergonomics mean stress-free usage
  • Seamless transition between scanning and touch-probing

Brochure

Brochure

PDF icon MMDx-MCAx_EN.pdf

Video

Video

ModelMaker MMDx Scanning Head

The ModelMaker MMDx handheld laser scanners are ideally suited for portable 3D inspection and reverse engineering applications. Its camera technology is a major leap forward in 3D laser scanning, as it introduces a high frame rate and a large stripe width up to 200mm for ultra-productive scanning. MMDx incorporates Enhanced Sensor Performance (ESP3) to scan all sample materials and surface finishes in a single move.

Key benefits:

  • Faster and more accurate scanning saves money and time
  • Ergonomic, light and small scanner
  • Scans almost all industrial materials
  • Portable out-of-the box system
  • Easy and fast plug & play set-up
  • Designed for use in all shop floor conditions
  • Optimized for hard-to-scan surfaces



Brochure

Brochure

PDF icon MMDx-MMCx_EN.pdf

Video

Video

H-120 ModelMaker Handheld Laser Scanner

More than two decades since the inception of the ModelMaker product line, the cutting-edge ModelMaker
H120 firmly pushes the ever-exacting boundaries of handheld laser scanning. Incorporating blue laser
technology, ultra-fast frame rate, specially developed Nikon optics and the ability to measure the most
challenging materials this represents the next generation of portable laser scanning. The H120 makes no
compromises in addressing the market needs by efficiently delivering the most detailed and accurate data
in a fraction of the time of competing technologies.

Key Benefits

- EXTREMELY LOW NOISE DATA - Nikon lens combined with blue laser technology
- UNEQUALLED PRECISION  - Scanner accuracy of 7 microns
- UNCOMPROMISING PERFORMANCE  - Measures at over 450 stripes every second on all materials
- ENHANCED USER EXPERIENCE - Full Field-of-View indicator for precise scanning
- MEASURE THE MOST CHALLENGING MATERIALS - Real-time optimization of the laser for every single measured point
- OPTIMIZED FOR ALL APPLICATIONS - Designed for use under all shop floor or field conditions
- Applications

- Fast & accurate multi-sensor 3D inspection
- Part-to-CAD inspection: First article inspection against CAD model
- Inspection of geometric features
- Gap-and-flush inspection
- Reverse engineering: from concept studio clay to class A surfaces
- Digitizing for additive manufacturing

Brochure

Brochure

PDF icon H120 & MCAx.pdf

Specifications

Specifications

Accuracy(1σ)1,2 7µm
Stripe width 120mm
Measuring range 50mm
Stand-off 80mm
Min. point resolution 35µm
Max. frame rate 450Hz
Max. points per stripe 2,000
Laser power adjustment ESP 4 (real-time per point)
Warm up time 0sec
Weight (approx.) 500g
Laser power Class              2,450nm
Field of view indicator Full FoV
Arm attachment Integrated

Video

Video

K-series: Optical CMM

The portable K-Series Optical CMM system forms the core of different metrology solutions. As it faces no mechanical constraints , users can freely walk around and measure points or scan surfaces as desired. The metrology area activated by the Optical CMM fits an entire vehicle and can be easily expanded. The Optical CMM is also suitable for measuring dynamic motion and researching transient events. Its third use relates to industrial robots. By tracking robot movement in real time, Optical CMM technology drives increased positional accuracy for robotized inspection and manufacturing tasks.

Key benefits:

  • Portable and mobile configuration offering easy setup and ergonomic operation
  • Full freedom measurements with walk-around SpaceProbe and K-Scan
  • Suited for lab, shop and field measurements
  • Large (17m3) and expandable measurement volume
  • Measurement object motion compensation through dynamic object referencing



Video

Video

Metronor SOLO Portable CMM System

Metronor SOLO is a portable CMM system based on Metronor’s patented principle that allows accurate 3D measurement with just one single camera and a hand-held probe. Metronor SOLO offers full CMM capability, including comparison of just about any geometry to CAD data or blueprint.

Ideally suited where fast setup, ease of use and high portability are critical, Metronor SOLO has a superior working volume and can be operated through a wireless connection – without cumbersome arms to balance or cables to untangle.

Highly affordable, Metronor SOLO provides excellent return on investment in industries as diverse as automotive, forging, machining, casting, energy and aerospace – as well as in numerous special applications such as high-radiation nuclear power plant maintenance or custom-fit boat decks. A special MIL-STD version of Metronor SOLO is also in operational use with several air forces as part of the ground support kit for maintenance of military jets, this adding to its credibility as being reliable, versatile and adaptable.

While highly capable on its own, it is also a very flexible investment and a wide range of options and upgrade paths are offered, permitting your Metronor SOLO to grow along with your future requirements or needs.

Benefits

- Complete and truly portable: One box, 24kg, for complete system including computer and tripod
- Extended probing capabilities including hidden features (450mm plus probe length)
- Operator friendly: Probing without beams, wires or arms
- Fast and easy set-up and use
- No warm-up, initialization or leap-frogging
- No moving parts eliminate re-calibration
- Can be upgraded to Metronor DUO and Metronor DUO Split system
- Price/performance winner

Contents

- Metronor camera CAM38 (110000) with 10m signal & power/sync cables
- SOLO/DUO tripod (711100) with Pan/tilt head (711000)
- LP89 Lightpen (116152) with WiFi communication and re-chargeable Li-Ion battery
- LP89 comes with spare Li-Ion battery and battery charger
- Standard Probe Kit (116200) and Calibration Tool (716400)
- Laptop computer for SOLO/DUO (714005)
- Interface Unit IU2 (714864)
- Metronor Metrolog EVO (331500), Metronor System SW (MSS) (330000) and SOLO technology license
- Required system and power cables
- Rollaway transportation case

Specifications

Specifications

APPLICATION SPECIFICATION  COMMENT
Range 1.5 – 25 m (5 – 80’) Distance from sensors
Measurement Volume 2000m3  70.000ft3
Profile measurements

 ±0.16 mm (5 m from camera)

±0.21 mm (10 m from camera)

±0.43 mm (20 m from camera)

600 mm wide profile orthogonal to camera optical axis

2 Sigma (U95)

Parallelism ±0.0033deg

Parallelism between 2 planes, 1000mm size

2 Sigma (U95)

Planarity  ±0.06mm

Planarity of single plane, size 2x2m2

2 Sigma (U95)

Small volume - 3D ±0.12mm

Volume up to 1.5 x 1.5 x 1.5 m3

Accuracy of 3D length

2 Sigma (U95)

Casting volume - 3D ±0.20mm

Volume up to 3.0 x 3.0 x 3.0 m3

Accuracy of 3D length (typical)

Environment

No warm-up

Operating Temperature: 10 to 45˚C (50 to 113˚F)

Storage Temperature: -25 to 65˚C (-13 to 150˚F)

Operating Humidity: < 95% relative humidity, non-condensing

Pressure, Humidity, Temperature: No effect on measurement accuracy

Vibration Stability Control (option): 0 – 100 Hz, < 3 mm amplitude

Electrical Power Auto switching (Battery operation optional) 100-240V AC, 50-60 Hz

Metronor DUO Portable CMM System

The Metronor DUO system combines large volume and increased accuracy, with the widest range of applications. Utilizing Metronor’s patented principle for electro-optical coordinate measurements, Metronor DUO is our most sought system, providing high-end coordinate measuring capability anywhere in the production process. Use the handheld probe to provide CMM capability – measure features such as holes, slots and edges as well as surfaces. Perform a GD&T analysis – or compare to CAD in real-time.

Compare tools, parts and assemblies to CAD or blue-print, use the LED application kit option to efficiently study stability, deformation and process repeatability, or take the system to your supplier or customer to investigate problems with interfacing parts. Metronor DUO also supports efficient alignment of objects in position and orientation (6 DOF) for example in tool building or jig-less assembly. Using two cameras and a hand-held, wireless probe, Metronor DUO provides accuracy, versatility and portability to address all your geometry-related issues.

Like all Metronor systems, it’s designed for use in rough shop floor environments and exhibits industry-leading reliability and availability. Also, at Metronor we develop modular systems. So a Metronor DUO can be easily upgraded to a Metronor DUO Split.  This boosts your investment – by purchasing a DUO you’re not only buying the tool to solve your geometry problems – it is an investment for the future. A system that can grow alongside your production.

Simple to operate, it is the most affordable high-end large-volume portable CMM system on the market. It is also extremely portable – the complete system comes in a single, roll-away transport case and weighs only 30 kilos (66 lbs).

Benefits

- Complete and truly portable: One box, 30kg, for complete system including computer and tripods
- Extended probing capabilities including hidden features (450mm with optional Light pen)
- Operator friendly: Probing without beams, wires or arms
- Fast and easy set-up and use
- No warm-up or leap-frogging required
- No moving parts eliminate re-calibration
- Can be upgraded  to DUET system if needs change
- High accuracy and flexibility

Contents

Pair of Metronor camera CAM38 (110000) with 10m signal & power/sync cables
- Two SOLO/DUO tripods (711100) with Pan/tilt head (711000)
- LP89 Lightpen (116152) with WiFi communication and re-chargeable Li-Ion battery
- LP89 comes with spare Li-Ion battery and battery charger
- Standard Probe Kit (116200) and Calibration Tool (716400)
- Reference bar RB68 (115150)
- Laptop computer for SOLO/DUO (714005)
- Interface Unit IU2 (714864)
- Metronor Metrolog EVO (331500), Metronor System SW (MSS) (330000) and SOLO technology license
- Required system and power cables
- Rollaway transportation case

Specifications

Specifications

APPLICATION SPECIFICATION COMMENT
Range Distance from sensors 1.5 – 15 m (5 – 50’)
Accuracy U95 distance measurement accuracy +/- 0.025 + L/60000mm
Environment No warm-up

Operating Temperature: 10 to 45˚C (50 to 113˚F)

Storage Temperature: -25 to 65˚C (-13 to 150˚F)

Operating Humidity < 95% relative humidity, non-condensing

Pressure, Humidity, Temperature: No effect on measurement accuracy

Vibration Stability Control (option): 0 – 100 Hz, < 3 mm amplitude

Electrical Power  Auto switching (Battery operation optional) 100-240 V AC, 50-60 Hz













Metronor Solo Twin System

Metronor SOLO Twin uses two separate cameras to generate each image. By effectively doubling the field-of-view, the camera can be placed closer to the measurement object, increasing accuracy and enabling measurement in one-set-up where several set-ups would otherwise be required.

During normal operation, the two cameras are mounted together on a special carbon fiber bracket ensuring optimal overlap and excellent stability.  Using a fast and simple procedure, the alignment between the two cameras can be re-determined anytime and anywhere, keeping system performance consistent over time – and after any rough handling or transportation.

Metronor SOLO Twin also enables special applications where it is critical to have two separate camera axes that are precisely known relative to each other. Such applications include alignment or inspection of parallel objects such as planes or bores – e.g. in gearboxes, thrusters, turbines, or other machinery.

Benefits

- High accuracy on large objects
- No setup – just measure
- Operator friendly: Probing without beams, cables or arms
- Tool certification within minutes
- Flexible and versatile
- Affordable capability
- Exceptional 70o field of view
- Unique solution for shaft alignment
- Ideal for narrow and crowded environments

Contents

- Pair of Metronor camera CAM38 (110000) with 10m signal & power/sync cables
- SOLO Twin Mounting Plate for CAM38 (711204)
- SOLO/DUO tripod (711100) with Pan/tilt head (711000)
- LP89 Lightpen (116152) with WiFi communication and re-chargeable Li-Ion battery
- LP89 comes with spare Li-Ion battery and battery charger
- Standard Probe Kit (116200) and Calibration Tool (716400)
- Laptop computer for SOLO/DUO (714005)
- Interface Unit IU2 (714864)
- Metronor Metrolog EVO (331500), Metronor System SW (MSS) (330000) and SOLO technology license
- Required system and power cables







Specifications

Specifications

APPLICATION SPECIFICATION COMMENT
Range 1.5 – 25 m (5 – 80’) Distance from sensors
Measurement Volume 2000m3 70.000ft3
Profile measurements

±0.16 mm (5 m from camera)

±0.21 mm (10 m from camera)

±0.43 mm (20 m from camera)

600 mm wide profile orthogonal to camera optical axis

2 Sigma (U95)

Parallelism ±0.0033deg

Parallelism between 2 planes, 1000mm size

2 Sigma (U95)

Planarity ±0.06mm

Planarity of single plane, size 2x2m2

2 Sigma (U95)

Small volume - 3D ±0.12mm

Volume up to 1.5 x 1.5 x 1.5 m3

Accuracy of 3D length

2 Sigma (U95)

Casting volume - 3D ±0.20mm

Volume up to 3.0 x 3.0 x 3.0m3

Accuracy of 3D length (typical)

Environment No warm-up

Operating Temperature: 10 to 45˚C (50 to 113˚F)

Storage Temperature: -25 to 65˚C (-13 to 150˚F)

Operating Humidity: < 95% relative humidity, non-condensing

Pressure, Humidity, Temperature: No effect on measurement accuracy

Vibration Stability Control (option): 0 – 100 Hz, < 3 mm amplitude

Electrical Power Auto switching (Battery operation optional) 100-240V AC, 50-60Hz
