Yu-shine

Vertical Boring Mills

VL-1200 ATC

VL-1200 ATC

Yu Shine has developed a variety of lathe machines to meet diverse market demands. The heavy duty vertical lathes made by Yu Shine have multiple capabilities suitable for high rigidity and high precision machining. Spindles powered by servo motor, high rigidity linear guide way and stable rotary hydraulic cylinder are all crucial to constantly advance accuracy and efficiency of a lathe machine; and that is what
we keep in mind when making a heavy duty vertical lathe. By offering time- and labor-saving heavy duty vertical lathe at competitive price, Yu Shine is able to provide the optimum solution for our customers from various industries. The features and specifications of heavy duty vertical lathes VL-ATC series are as below. For further details or help, please feel free to contact us at anytime.

• Machine bed is made of meehanite cast iron for good rigidity.
• Chuck headstock with powerful coolant system for efficient chip removal.
• Easy loading/unloading, suitable for big, heavy, irregular shape workpieces.
• Maintains the best circularity without inertial ellipse after machining.
• Solid, heavy duty table face permits close-in fixturing for high-rigidity, vibration free machining.
• Smallest footprint in its class, offering the best work flow available.

Specifications

Specifications

Max. Swing Diameter Ø 1650mm
Max. Cutting Diameter Ø 1360mm
Max. Cutting Height 1200mm
Max. Cutting Force 2500kgf
Max. Table Load 5000kg
Table Diameter     1250mm
Table Speed 2-350rpm
Max. Tool Weight 50kg
Time for Tool Change  30sec
X Axis Stroke 1000mm
Z Axis Stroke 900mm
X&Z Axis Rapid Feedrate 10m/min
Cutting Speed 0.01-50rpm



VL-850 HLR

• Machine bed is made of meehanite cast iron for good rigidity.
• Chuck headstock with powerful coolant system for efficient chip removal.
• Easy loading/unloading, suitable for large, heavy, irregularly shaped workpieces.
• Maintains high circularity without inertial ellipse after machining.
• Solid, heavy duty table face allows close-in fixturing for high-rigidity, vibration free machining.
• Smallest footprint in its class, offering the best work flow available.

Specifications

Specifications

Max. Swing Dia. Ø1000mm
Max. Turning Dia. Ø850mm
Max. Turning Height 700mm
Spindle Nose A2-11
X-Axis Travel 500mm
Y-Axis Travel 800mm
Spindle Speed 20~1500rpm
Spindle Motor 37/45 kw
Machine (LxW) 4285x4650mm
Machine (H) 4020mm
Machine Weight 13500kg x 2



VL-1000 ATC

Yu Shine has developed a variety of lathe machines to meet diverse market demands. The heavy duty vertical lathes made by Yu Shine have multiple capabilities suitable for high rigidity and high precision machining. Spindles powered by servo motor, high rigidity linear guide way and stable rotary hydraulic cylinder are all crucial to constantly advance accuracy and efficiency of a lathe machine; and that is what
we keep in mind when making a heavy duty vertical lathe. By offering time- and labor-saving heavy duty vertical lathe at competitive price, Yu Shine is able to provide the optimum solution for our customers from various industries. The features and specifications of heavy duty vertical lathes VL-ATC series are as below. For further details or help, please feel free to contact us at anytime.

• Machine bed is made of meehanite cast iron for good rigidity.
• Chuck headstock with powerful coolant system for efficient chip removal.
• Easy loading/unloading, suitable for big, heavy, irregular shape workpieces.
• Maintains the best circularity without inertial ellipse after machining.
• Solid, heavy duty table face permits close-in fixturing for high-rigidity, vibration free machining.
• Smallest footprint in its class, offering the best work flow available.

VL-1600 ATC

Yu Shine has developed a variety of lathe machines to meet diverse market demands. The heavy duty vertical lathes made by Yu Shine have multiple capabilities suitable for high rigidity and high precision machining. Spindles powered by servo motor, high rigidity linear guide way and stable rotary hydraulic cylinder are all crucial to constantly advance accuracy and efficiency of a lathe machine; and that is what
we keep in mind when making a heavy duty vertical lathe. By offering time- and labor-saving heavy duty vertical lathe at competitive price, Yu Shine is able to provide the optimum solution for our customers from various industries. The features and specifications of heavy duty vertical lathes VL-ATC series are as below. For further details or help, please feel free to contact us at anytime.

• Machine bed is made of meehanite cast iron for good rigidity.
• Chuck headstock with powerful coolant system for efficient chip removal.
• Easy loading/unloading, suitable for big, heavy, irregular shape workpieces.
• Maintains the best circularity without inertial ellipse after machining.
• Solid, heavy duty table face permits close-in fixturing for high-rigidity, vibration free machining.
• Smallest footprint in its class, offering the best work flow available.

VL-2000 ATC

Yu Shine has developed a variety of lathe machines to meet diverse market demands. The heavy duty vertical lathes made by Yu Shine have multiple capabilities suitable for high rigidity and high precision machining. Spindles powered by servo motor, high rigidity linear guide way and stable rotary hydraulic cylinder are all crucial to constantly advance accuracy and efficiency of a lathe machine; and that is what
we keep in mind when making a heavy duty vertical lathe. By offering time- and labor-saving heavy duty vertical lathe at competitive price, Yu Shine is able to provide the optimum solution for our customers from various industries. The features and specifications of heavy duty vertical lathes VL-ATC series are as below. For further details or help, please feel free to contact us at anytime.

• Machine bed is made of meehanite cast iron for good rigidity.
• Chuck headstock with powerful coolant system for efficient chip removal.
• Easy loading/unloading, suitable for big, heavy, irregular shape workpieces.
• Maintains the best circularity without inertial ellipse after machining.
• Solid, heavy duty table face permits close-in fixturing for high-rigidity, vibration free machining.
• Smallest footprint in its class, offering the best work flow available.

VL-2500 ATC

Yu Shine has developed a variety of lathe machines to meet diverse market demands. The heavy duty vertical lathes made by Yu Shine have multiple capabilities suitable for high rigidity and high precision machining. Spindles powered by servo motor, high rigidity linear guide way and stable rotary hydraulic cylinder are all crucial to constantly advance accuracy and efficiency of a lathe machine; and that is what
we keep in mind when making a heavy duty vertical lathe. By offering time- and labor-saving heavy duty vertical lathe at competitive price, Yu Shine is able to provide the optimum solution for our customers from various industries. The features and specifications of heavy duty vertical lathes VL-ATC series are as below. For further details or help, please feel free to contact us at anytime.

• Machine bed is made of meehanite cast iron for good rigidity.
• Chuck headstock with powerful coolant system for efficient chip removal.
• Easy loading/unloading, suitable for big, heavy, irregular shape workpieces.
• Maintains the best circularity without inertial ellipse after machining.
• Solid, heavy duty table face permits close-in fixturing for high-rigidity, vibration free machining.
• Smallest footprint in its class, offering the best work flow available.

VL-3000

Yu Shine has developed a variety of lathe machines to meet diverse market demands. The heavy duty vertical lathes made by Yu Shine have multiple capabilities suitable for high rigidity and high precision machining. Spindles powered by servo motor, high rigidity linear guide way and stable rotary hydraulic cylinder are all crucial to constantly advance accuracy and efficiency of a lathe machine; and that is what
we keep in mind when making a heavy duty vertical lathe. By offering time- and labor-saving heavy duty vertical lathe at competitive price, Yu Shine is able to provide the optimum solution for our customers from various industries. The features and specifications of heavy duty vertical lathes VL-ATC series are as below. For further details or help, please feel free to contact us at anytime.

• Machine bed is made of meehanite cast iron for good rigidity.
• Chuck headstock with powerful coolant system for efficient chip removal.
• Easy loading/unloading, suitable for big, heavy, irregular shape workpieces.
• Maintains the best circularity without inertial ellipse after machining.
• Solid, heavy duty table face permits close-in fixturing for high-rigidity, vibration free machining.
• Smallest footprint in its class, offering the best work flow available.

Vertical Turning Centers

VL-350R

Yu Shine has developed a variety of lathe machines to meet diverse market demands. The CNC vertical lathes made by Yu Shine have multiple capabilities suitable for high rigidity and high precision machining. Spindles powered by servo motor, high rigidity linear guide way and stable rotary hydraulic cylinder are all crucial to constantly advance accuracy and efficiency of a lathe machine; and that is what we keep in mind when making a CNC vertical lathe. By offering time- and labor-saving CNC vertical lathe at competitive price, Yu Shine is able to provide the optimum solution for our customers from various industries. The features and specifications of CNC vertical lathe VL-HR Series are as below. For further details or help, please feel free to contact us at anytime.

- Machine bed is made of meehanite cast iron for good rigidity.
- Chuck headstock with powerful coolant system for efficient chip removal.
- Easy loading/unloading, suitable for big, heavy, irregular shape workpieces.
- Maintains the best circularity without inertial ellipse after machining.
- Solid, heavy duty table face permits close-in fixturing for high-rigidity, vibration free machining.
- Smallest footprint in its class, offering the best work flow available.

Specifications

Specifications

Model: VL-350R
Max.Swing Dia: Ø450
Max. Cutting Dia: Ø350
Max. Cutting Height: 400
Main Spindle Motor: αP18(9/11)

Machine Size
Machine(L): 2900
Machine(W): 1500
Machine(H): 2500
Machine Weight: 3500

VL-450R

Yu Shine has developed a variety of lathe machines to meet diverse market demands. The CNC vertical lathes made by Yu Shine have multiple capabilities suitable for high rigidity and high precision machining. Spindles powered by servo motor, high rigidity linear guide way and stable rotary hydraulic cylinder are all crucial to constantly advance accuracy and efficiency of a lathe machine; and that is what we keep in mind when making a CNC vertical lathe. By offering time- and labor-saving CNC vertical lathe at competitive price, Yu Shine is able to provide the optimum solution for our customers from various industries. The features and specifications of CNC vertical lathe VL-HR Series are as below. For further details or help, please feel free to contact us at anytime.

- Machine bed is made of meehanite cast iron for good rigidity.
- Chuck headstock with powerful coolant system for efficient chip removal.
- Easy loading/unloading, suitable for big, heavy, irregular shape workpieces.
- Maintains the best circularity without inertial ellipse after machining.
- Solid, heavy duty table face permits close-in fixturing for high-rigidity, vibration free machining.
- Smallest footprint in its class, offering the best work flow available.

Specifications

Specifications

Model: VL-450R
Max.Swing Dia: Ø550
Max. Cutting Dia: Ø450
Max. Cutting Height: 450
Main Spindle Motor: αP22(11/15)

Machine Size
Machine(L): 3000
Machine(W): 1500
Machine(H): 2600
Machine Weight: 4500

VL-600R

Yu Shine has developed a variety of lathe machines to meet diverse market demands. The CNC vertical lathes made by Yu Shine have multiple capabilities suitable for high rigidity and high precision machining. Spindles powered by servo motor, high rigidity linear guide way and stable rotary hydraulic cylinder are all crucial to constantly advance accuracy and efficiency of a lathe machine; and that is what we keep in mind when making a CNC vertical lathe. By offering time- and labor-saving CNC vertical lathe at competitive price, Yu Shine is able to provide the optimum solution for our customers from various industries. The features and specifications of CNC vertical lathe VL-HR Series are as below. For further details or help, please feel free to contact us at anytime.

- Machine bed is made of meehanite cast iron for good rigidity.
- Chuck headstock with powerful coolant system for efficient chip removal.
- Easy loading/unloading, suitable for big, heavy, irregular shape workpieces.
- Maintains the best circularity without inertial ellipse after machining.
- Solid, heavy duty table face permits close-in fixturing for high-rigidity, vibration free machining.
- Smallest footprint in its class, offering the best work flow available.

Specifications

Specifications

Model: VL-600R
Max.Swing Dia: Ø650
Max. Cutting Dia: Ø600
Max. Cutting Height: 500
Main Spindle Motor: αP30(15/18.5)

Machine Size
Machine(L): 3100
Machine(W): 1510
Machine(H): 2910
Machine Weight: 5500

VL-750HR

Yu Shine has developed a variety of lathe machines to meet diverse market demands. The CNC vertical lathes made by Yu Shine have multiple capabilities suitable for high rigidity and high precision machining. Spindles powered by servo motor, high rigidity linear guide way and stable rotary hydraulic cylinder are all crucial to constantly advance accuracy and efficiency of a lathe machine; and that is what we keep in mind when making a CNC vertical lathe. By offering time- and labor-saving CNC vertical lathe at competitive price, Yu Shine is able to provide the optimum solution for our customers from various industries. The features and specifications of CNC vertical lathe VL-HR Series are as below. For further details or help, please feel free to contact us at anytime.

- Machine bed is made of meehanite cast iron for good rigidity.
- Chuck headstock with powerful coolant system for efficient chip removal.
- Easy loading/unloading, suitable for big, heavy, irregular shape workpieces.
- Maintains the best circularity without inertial ellipse after machining.
- Solid, heavy duty table face permits close-in fixturing for high-rigidity, vibration free machining.
- Smallest footprint in its class, offering the best work flow available.

Specifications

Specifications

Model: VL-750R
Max.Swing Dia: Ø780
Max. Cutting Dia: Ø750
Max. Cutting Height: 650 850(Opt.)
Main Spindle Motor: αP30(15/18.5)

Machine Size
Machine(L): 3400
Machine(W): 1780
Machine(H): 3520
Machine Weight: 9000

VL-850R

Yu Shine has developed a variety of lathe machines to meet diverse market demands. The CNC vertical lathes made by Yu Shine have multiple capabilities suitable for high rigidity and high precision machining. Spindles powered by servo motor, high rigidity linear guide way and stable rotary hydraulic cylinder are all crucial to constantly advance accuracy and efficiency of a lathe machine; and that is what we keep in mind when making a CNC vertical lathe. By offering time- and labor-saving CNC vertical lathe at competitive price, Yu Shine is able to provide the optimum solution for our customers from various industries. The features and specifications of CNC vertical lathe VL-HR Series are as below. For further details or help, please feel free to contact us at anytime.

- Machine bed is made of meehanite cast iron for good rigidity.
- Chuck headstock with powerful coolant system for efficient chip removal.
- Easy loading/unloading, suitable for big, heavy, irregular shape workpieces.
- Maintains the best circularity without inertial ellipse after machining.
- Solid, heavy duty table face permits close-in fixturing for high-rigidity, vibration free machining.
- Smallest footprint in its class, offering the best work flow available.

Specifications

Specifications

Model: VL-850HR
Max.Swing Dia: Ø1000
Max. Cutting Dia: Ø850
Max. Cutting Height: 750 950(Opt.)
Main Spindle Motor: αP30(15/18.5)

Machine Size
Machine(L): 4285
Machine(W): 2300
Machine(H): 4020
Machine Weight: 13000


VL-1000HR

Yu Shine has developed a variety of lathe machines to meet diverse market demands. The CNC vertical lathes made by Yu Shine have multiple capabilities suitable for high rigidity and high precision machining. Spindles powered by servo motor, high rigidity linear guide way and stable rotary hydraulic cylinder are all crucial to constantly advance accuracy and efficiency of a lathe machine; and that is what we keep in mind when making a CNC vertical lathe. By offering time- and labor-saving CNC vertical lathe at competitive price, Yu Shine is able to provide the optimum solution for our customers from various industries. The features and specifications of CNC vertical lathe VL-HR Series are as below. For further details or help, please feel free to contact us at anytime.

- Machine bed is made of meehanite cast iron for good rigidity.
- Chuck headstock with powerful coolant system for efficient chip removal.
- Easy loading/unloading, suitable for big, heavy, irregular shape workpieces.
- Maintains the best circularity without inertial ellipse after machining.
- Solid, heavy duty table face permits close-in fixturing for high-rigidity, vibration free machining.
- Smallest footprint in its class, offering the best work flow available.

Specifications

Specifications

Model: VL-1000HR
Max.Swing Dia: Ø1200
Max. Cutting Dia: Ø1000
Max. Cutting Height: 750 950(Opt.)
Main Spindle Motor: αP30(18.5/22)

Machine Size
Machine(L): 4435
Machine(W): 2900
Machine(H): 4020
Machine Weight: 15000

VL-1100HR

Yu Shine has developed a variety of lathe machines to meet diverse market demands. The CNC vertical lathes made by Yu Shine have multiple capabilities suitable for high rigidity and high precision machining. Spindles powered by servo motor, high rigidity linear guide way and stable rotary hydraulic cylinder are all crucial to constantly advance accuracy and efficiency of a lathe machine; and that is what we keep in mind when making a CNC vertical lathe. By offering time- and labor-saving CNC vertical lathe at competitive price, Yu Shine is able to provide the optimum solution for our customers from various industries. The features and specifications of CNC vertical lathe VL-HR Series are as below. For further details or help, please feel free to contact us at anytime.

- Machine bed is made of meehanite cast iron for good rigidity.
- Chuck headstock with powerful coolant system for efficient chip removal.
- Easy loading/unloading, suitable for big, heavy, irregular shape workpieces.
- Maintains the best circularity without inertial ellipse after machining.
- Solid, heavy duty table face permits close-in fixturing for high-rigidity, vibration free machining.
- Smallest footprint in its class, offering the best work flow available.

Specifications

Specifications

Model: VL-1100HR
Max.Swing Dia: Ø1250
Max. Cutting Dia: Ø1100
Max. Cutting Height: 1000
Main Spindle Motor: αP30(37/45)

Machine Size
Machine(L): 4500
Machine(W): 2520
Machine(H): 4605
Machine Weight: 18000
